Amprobe AT 5005 Underground Cable / Pipe Locator System
Enlarge Image
Amprobe AT 5005
Request Quote Print Page

Underground Cable / Pipe Locator System
Amprobe AT 5005 Features
  • Locates underground energized and de-energized wires, cables and pipes, eliminates exploratory digging in parking lots or under floors for buried pipes and wires
  • Signal Select and Distortion Alert icon indicates clean signal of the traced line, versus "ghost" and "return" path signals coming from the neighboring lines
  • Three testing modes for best accuracy:
    • Passive Power Mode (50, 60, 100 and 120 Hz) – tracing energized lines conducting current
    • Passive Radio Mode (RF) – using surrounding radio waves to trace underground object
    • Active Mode - T-5000 signal generator with broad frequency selection between 491 Hz and 166 kHz with induction mode or directly connected to the cable with test leads or optional clamp
  • Active Mode Depth measurement up to 20" (6m)
  • Bright Color ¼ VGA receiver graphical display and audible signal indicators provide clear reading to the user
  • Strong testing signal generated by 10 Watt variable output transmitter for dependable depth and distance locating
  • Powerful Digital Signal Processing in both receiver and transmitter provides outstanding performance in tracing when compared to analog devices
  • Automatic or manual gain mode allows respectively quick and easy tracing of the line or precise pinpointing of the fault
  • Receiver Bluetooth wireless communication for downloading relevant images and archiving of meaningful digital information (previous survey results)
  • Precise pinpointing of buried services and exceptionally fast sound and meter response
  • Rugged durable construction, weatherproof and drop resistant to 3"
  • Includes receiver (R-5000), transmitter (T-5000), connection cable, ground stake, ground cable, and carrying case and A-Frame
Amprobe AT 5005 Specs
Depth Measurement 20 ft
Passive Tracing Frequencies 50, 60, 100 and 120 Hz
Transmitter frequency Adjustable from 491 to 166 kHz
R-5000 Active Frequencies (Hz) 491, 982, 8.44k, 9.82k, 35k, 82k, 83k (North America)
491, 512, 577, 640, 982, 8k, 8.44k, 9.82k, 35k, 65.5k, 82k, 83k
R-5000 Passive Frequencies (Hz) 50, 60, 100, 120, RF (14k-21k)
Extended and special frequency sets available
R-5000 Depth Display Accuracy 0-10ft: ±(5%+2”) under ideal field conditions 10-20ft: ±10% under ideal field conditions
R-5000 Depth Range Maximum 20ft (600 cm)
R-5000 Gain Adjustment Automatic & manual with push-button centering
R-5000 Controls Four-way navigation key and soft keys
R-5000 Line ID Signal Select, Guidance Compass, Distortion Alert
R-5000 Display ¼ VGA Bright Color
R-5000 Antenna Distance Sensitive Left/Right Guidance
R-5000 Data Acquisition Internal data logging memory
R-5000 Operating Temperature -4°F to +122°F (-20°C to +50°C)
R-5000 Battery Type Li-ion rechargeable 9 AA Alkaline
R-5000 Battery Life 30 hours continuous
R-5000 Battery Check Continuous display
R-5000 Dimensions 8 ¼” W x 13 ¼” H x 29” L (21.0cm x 33.7 cm x 74.3cm)
R-5000 Weight 4.9 lb (2.2 kg)
R R-5000 regulatory Compliance FCC, CE
R-5000 Environmental IP54
T-5000 Output Power Variable to 10W
T-5000 Simultaneous Output Up to three active frequencies
T-5000 Controls Frequency select, measurement units (mA, Volts, Ohms, Watts), output power, Signal Select™, menu, 4-way navigation, select, SFL, On/Off
T-5000 Display Indicators Battery status, audio volume, output mode, frequency setting, frequency out put, % output in SFL or induction mode, output graph, loop resistance graph
T-5000 Display 1/8 VGA monochrome
T-5000 Battery Type NiMH rechargeable or six (6) D alkaline
T-5000 Battery Life 6 – 12 hours continuous use, depending on power level and line conditions
T-5000 Operation Temperature -4°F to +122° F (-20°C to +50° C)
T-5000 Dimensions 11” W x 6 ¾” H x 9” L (27.9 cm x 17.1 cm x 22.9 cm)
T-5000 Weight 8.24 lbs. (3.7 kg)
T-5000 Regulatory Compliance FCC, CE
T-5000 Environmental IP54
