| Output Frequencies |
| Trace Mode: |
577Hz, 8kHz, 33kHz, 200kHz |
| Sheath (Earth Return) Fault Mode: |
10/20 Hz for sheath (earth return) fault; 577Hz and 33kHz for tracing |
| Tone Mode: |
577Hz and 200kHz pulsed at 8Hz |
| Induction Mode: |
33kHz, 200kHz |
| Output Voltage |
| Sheath (Earth Return) Fault: |
70 Vrms |
| Trace: |
70 Vrms |
| Tone: |
Normal setting: 10 Vrms, High setting: 60 Vrms |
| Output Power: |
Normal setting: Limited to 0.5W
High setting: Limited to 3W, or 5W with External DC power |
