The Sonel UV-260 is an ultraviolet (UV) corona camera that detects, pinpoints and registers flash-arc corona and arcing partial discharge. The UV-260's high sensitivity to UV signals allows the instrument to detect UV emissions in full daylight from near or distant sources. Using non-destructive testing technology makes the Sonel UV-260 an ideal predictive maintenance instrument for overhead transmission lines and high voltage substations. UV radiation emissions are exposed on the UV-260's 5.7-inch color LCD touch-screen. Once the UV radiation is detected, the user can snapshot or record a video for further analysis.
Features
- High sensitivity to UV signals.
- Precise location of corona emitting sources.
- Auto focus of UV and visible channels.
- Back ground noise reduction.
- 5.7" folding and touchable color LCD.
- Sound or LED UV events alarm.
- Fast optical zoom of the visible channel.
- Videos & images capturing, recording and playback.
- Built-in GPS.
- UV events counter.
- UV-260 report software for documentation.
Specifications
| Visible - Optical Properties |
| Image Type: |
Color video |
| UV/Visible Overlay Accuracy: |
Better than 1 milliradian |
| Minimum Visible Light Sensitivity: |
0.1 lux |
| Zoom Factor: |
26x optical and 12x digital |
| UV - Optical Properties |
| Image Type: |
Monochrome video |
| Minimum UV Sensitivity |
3 x 10 -18 watt / cm² |
| Minimum Discharge Detection |
1.5pC @ 8 meters |
| Spectral Range |
UV 240 - 280 nm |
| Field of View H x V |
5.5° x 4.0° |
| Focus |
Full manual and auto for UV and visible channels |
| Focus Distance |
2 m...∞ |
| Detector Life Span |
No degradation |
| Frequency |
50Hz/60 Hz |
| Display |
| Type |
5.7" VGA color LCD, folding and touchable |
| Video Standard |
PAL/NTSC switchable |
| Modes |
Combined (UV & visible), UV only, Visible only |
| Corona Shades |
Whites, Red, Blue |
Applications
The Sonel UV-260 Corona Camera has many applications including HV electrical component inspection, HV panel inspection, and transmission line inspection. This instrument is ideal for electrical uility companies, service providers, laboratories and more.
