Yokogawa DL850EV ScopeCorder Oscilloscope
- 8 Slots
- 120 channels per slot, 336 channels per unit
- Insulation Resistance: >10M Ω
Yokogawa DL750P ScopeCorder
- Max memory for high-speed sampler: 100 MW
- Time Axis Accuracy: ±(0.005%)
- 6 DSP Channels
Yokogawa DL850 ScopeCorder 100 MS/s, 8 slots
- High-speed (up to 100 MS/s), High Resolution (up to 16-bit), Isolated (up to 1kV*1)
- Multi-channel, up to 128 voltage or 128 logic bits
- Continuous hard disk recording at 100 kS/s simultaneously on 16 channels*2
AstroNova TMX-18 Portable Data Recorder (Astro-Med)
- 17" LCD high-resolution touch screen display
- 18 channels of voltage & DC bridge inputs
- Dedicated 1 TB removable hard drive for data capture
Yokogawa DL750 ScopeCorder 10 MS/s, 16 Channel, 8 Slots
- Integration of a High-Speed sampler (Oscilloscope) and Low-Speed sampler (Recorder) in a Single Unit
- Separate Memory Management for Each sampler
- High-Speed Sampling Triggered Only by Abnormal Events Occurring during Long-Term Observation (Low-Speed Sampling)
Tektronix MSO5000B & DPO5000B Series Oscilloscopes
- Characterize signal parameters with a broad suite of standard measurement tools
- Advanced jitter and timing analysis characterizes signal integrity issues and their sources
- SignalVu software provides wideband spectral analysis and measurements, with options for audio, modulation, RF pulses, and settling time
Tektronix TDS5054B 4 Channel 500 MHz 5 GS/s Digital Oscilloscope
- 500 MHz Bandwidth Model
- 4 Channel Models
- 5 GS/s Sample Rate
LeCroy HDO6104A High Definition Oscilloscope
- 12-bit ADC resolution, up to 15 bits with enhanced resolution
- Up to 10 GS/s with Enhanced Sample Rate
- 350 MHz, 500 MHz, and 1 GHz bandwidths
Keysight MSO9404A Infiniium Oscilloscope, 4 GHz / 4 CH
- Engineered for the broadest measurement capability: 4 GHz bandwidth across all 4 analog channels 4 analog channels +16 digital channels 20 GSa/s max. sample rat Standard 20 Mpts
- 4 GHz bandwidth across all 4 analog channels
- 4 analog channels +16 digital channels
Tektronix TDP1000 High Voltage Differential Probe | 1 GHz
- 1 GHz probe bandwidth
- Selectable bandwidth-limiting filters
- Versatile DUT connectivity
Tektronix MDO4054B-6 Mixed Domain Oscilloscope
- Mixed-domain analysis Time-correlated analog, digital, and RF signal acquisitions in a single instrument Wave Inspector controls provide easy navigation of time-correlated data from both the
- Time-correlated analog, digital, and RF signal acquisitions in a single instrument
- Wave Inspector controls provide easy navigation of time-correlated data from both the time and frequency domains
Tektronix P5210 High Voltage Differential Probe
- 7ns Rise Time
- 5 MHz
- 16 MΩ, 3.5 pF between inputs
Keysight DSO9104H High-Definition Oscilloscope
- 1 GHz frequency range
- 100 Mpts memory
- 12 bits of resolution / 4096 quantization levels @ < 500 MHz
Tektronix MDO4054B-3 Mixed Domain Oscilloscope
- Mixed-domain analysis Time-correlated analog, digital, and RF signal acquisitions in a single instrument Wave Inspector controls provide easy navigation of time-correlated data from both the
- Time-correlated analog, digital, and RF signal acquisitions in a single instrument
- Wave Inspector controls provide easy navigation of time-correlated data from both the time and frequency domains
Keysight InfiniiVision DSO7104B Oscilloscope 1 GHz
- 100 MHz, 350 MHz, 500 MHz and 1 GHz models
- Up to 4 GSa/s sample rate
- 2+16 & 4+16 Channel mixed signal (MSO) models
Tektronix MDO4014-3 Mixed Domain Oscilloscope
- Mixed-domain analysis Time-correlated analog, digital, and RF signal acquisitions in a single instrument Wave Inspector controls provide easy navigation of time-correlated data from both the
- Time-correlated analog, digital, and RF signal acquisitions in a single instrument
- Wave Inspector controls provide easy navigation of time-correlated data from both the time and frequency domains
LeCroy WaveRunner 64 Xi Oscilloscope 600 MHz, 4 Ch
- Sequence Acquisition Mode to optimize capture, viewing, and understanding of events that are spaced far apart in time.
- Extensive pass/fail capability with multiple conditions and limits, and flexibility to choose the action that is enabled when the conditions are satisfied.
- Creation of user-customized measurement parameters or math functions using Excel, MATLAB, Mathcad or VBScripts.
Yokogawa DL350 Portable ScopeCorder
- A4-sized compact chassis
- Simultaneous isolated inputs maximum 8-ch (1 MS/s) or 4-ch (100 MS/s) Scanning inputs maximum 32-ch (10 kS/s) or 16 channels (20 kS/s)
- AC/DC/Battery operated
Yokogawa 701921 100 Mhz Differential Probe
- Test range: 700 V - 100 MHz
- Bandwidth of DC to 100 MHz
- Output voltage: ±7 V (DC or ACpeak)
Fluke 190-502 | 500 MHz 5 GS/s 2 channel
- Up to four independent floating isolated inputs, up to 1000 V Up to 5 GS/s real time sampling (Depending on model and channels used)
- Deep memory: 10,000 points per trace waveform capture (scope mode)
- CAT III 1000 V/CAT IV 600 V safety rated instrument for industrial environments
Tektronix MSO3014 Mixed Signal Oscilloscope
- Up to 4 analog and 16 digital channels
- Digital phosphor display
- Complete set of triggers
Agilent 1134A InfiniiMax 7 GHz Active Probe
- Supports differential and single-ended measurements
- Common mode rejection of the differential probe reduces the noise floor
- Flat frequency response to eliminate distortion
Yokogawa 700929 10:1 Probe
- Bandwidth: DC to 100MHz (-3dB)
- Attenuation ratio: 10:1
- Connector Type: BNC
Keysight 16712A Timing Analysis Module 100 MHz / 500 MHz
- State and timing analysis through the same probe
- Capture up to 204, 128K deep channels simultaneously
- Refer to data sheet for more information
Keysight 16534A 2 GSa/s 2-Channel 500 MHz BW Digitizing Oscilloscope Module
- 500 MHz Bandwidth
- 2 Gsa/s sampling
- 2 channels
