APT 340XAC 1Ø 4kVA / 3Ø 12kVA Modular AC Power Source

Need Help? Call (800) 404-2832ATEC AssuranceWorldwide Delivery
Rent APT 340XAC 1Ø 4kVA / 3Ø 12kVA Modular AC Power Source
Enlarge Image
Associated Power Technologies 340XAC
Request Quote Print Page
340XAC Datasheet
The APT 340XAC 1Ø 4kVA / 3Ø 12kVA Modular AC Power Source incorporates the latest in modular technology, making it ideal for the most demanding applications. This versatile AC power source can be configured for 1Φ stand-alone operation or linked together for up to 18 kVA of AC power in both 1Φ and 3Φ output configurations.

The smartDETECT® feature automatically assigns the appropriate master/slave designation for each source without the need for the operator to reconfigure internal hardware. The easy-to-use push-button interface allows the operator to select 1Φ or 3Φ operation, setup and perform tests, and simulate the effect of voltage surges and drops for transient testing.
Associated Power Technologies 340XAC Features
  • Modular design allows operator to connect up to 3 instruments together for 1Φ or 3Φ applications requiring up to 18 kVA of AC power
  • Configure 2 sources for 1Φ/3W output voltages up to 600 VAC
  • smartCONFIG® feature allows for push-button setup of 1Φ/3Φ output
  • 50 built-in memory locations with 9 test steps can be linked to quickly store and recall test parameters for multiple product testing applications
  • Transient feature simulates voltage variations, brownouts, and transient voltage conditions
  • Adjust the starting and ending angle of the output waveform
  • Prompt feature allows operator to display instructions between test steps
  • Frequency output up to 1000 Hz
  • Constant current output with over current fold back feature
  • Advanced metering circuits monitor voltage, current, peak current, power, apparent power, reactive power, power factor, and crest factor
  • External voltage sensing for accurate metering
  • DC Output Capability
  • Standard USB/RS-232 interface with optional GPIB and Ethernet interfaces available at no extra charge
  • Rotary knob to adjust voltage and frequency on the fly
Associated Power Technologies 340XAC Specs
  • Input
    • Phase: 1Φ
    • Voltage: 180 - 264 VAC
    • Frequency: 47 - 63 Hz
  • Output
    • Voltage: 5 - 300 V
    • Max Power: 4 kVA
    • Max Current 1Φ
      • 0 - 150 V: 36.8 A @ 110 V
      • 0 - 300 V: 18.4 A @ 220 V
  • DC Output Voltage
    • Voltage: 5 - 420 V
    • Max Power: 4000 W
    • Max Current 1Φ
      • 0 - 210 V: 19.2 A
      • 0 - 420 V: 9.6 A
  • Option 2: Grounded Neutral
  • Option 3: GPIB Interface
  • Option 4: 7 Remote Memory
  • Option 6: Ethernet Interface
  • Option 8: Linking Card
