Preen AFV-PLUS-33200 AC Power Source

The Preen AFV-PLUS-33200 AC Power Source has an output power of 200 kVA and an output frequency range of 45 to 500 Hz. It is a 3-phase AC power source, featuring multiple output modes and a remote control function. The AFV-PLUS-33200 has an input power of 480 V and operates within the temperature range from 0°C to 45°C.

Product Info Related Products

Input	Voltage: 480 V Frequency: 50 Hz ±3 Hz or 60 Hz ±3 Hz
Output	Power: 200 kVA Voltage: 0 V - 150 V (low) 0 - 300 V (high) Frequency range: 45 - 65 Hz
Phase	3Ø / 4 wire + G
Voltage resolution	0.1 V
Voltage accuracy	0.5% F.S. +4 counts
Total Harmonic distortion	2% (resistive load)
Response time	2 ms
Measurement	Voltage range: 0 - 300 V Frequency range: 45 - 500 Hz Current range (RMS): 0 - 555.6 A
Efficiency	≥0.85 at max. power
Operation temperature	0°C - 45°C
Dimensions (H x W x D)	1900 x 1150 x 1240 mm (74.8 x 45.27 x 48.81 in)
Weight	2300 kg (5072 lb.)

200 kVA output power
Voltage output: 300V
Output frequency: standard 45 - 65Hz
3 phase input and output
CE & RoHS certificated
Modularized inverter which is compact, smaller, high power density, and easy to maintain
7-inch touchscreen
Ability to simulate abnormal power status: STEP and GRADUAL change modes
Comprehensive protections
Phase angle adjustment function
Multiple output modes
Remote control

Variation Test
Life Cycle Test

SKU: PREE-AFV-PLUS-33200
