Hioki 3169-20 Clamp-On Power HiTester

Need Help? Call (800) 404-2832ATEC AssuranceWorldwide Delivery
Hioki 3169-20
Enlarge Image
Hioki 3169-20 Hioki 3169-20
Hioki 3169-20
Request Quote Print Page

The Hioki 3169-20 Clamp On Power HiTESTER allows measurement of single-phase to three-phase 4-wire circuits with a single unit. In addition to measuring standard parameters such as voltage, current, power, power factor, and integrated values, these clamp-on power meters can simultaneously perform demand measurements required for carrying out power management and energy-saving measures, as well as harmonic measurements.

The Hioki 3169 power meter also features PC card data storage, and comes equipped with an RS-232C interface for PC communications. Further, with greater data processing speeds, it is possible to measure the power of just a few cycles, enabling more detailed and effective energy-saving measures for equipment. The Hioki 3169-20 is ideal for users who want to achieve close control over energy-saving management activities and measures.

Hioki 3169-20 Features
  • Measure up to 3-phase, 3-wire system (displays voltage and current for three lines)
  • Measure up to four single-phase, 2-wire systems
  • 5A to 5000A range
  • Compact and light weight
  • PC card data storage
  • Power recording for individual waveforms
  • Simultaneous recording of demand values and harmonics
Hioki 3169-20 Specs
Measurement lines Single-phase/two-wires, Single-phase/three-wires, Three-phase/three-wires, Three-phase/four-wires
Measurement items Voltage, Current, Active power, Apparent power, Reactive power, Power factor, Frequency, Power integral, Harmonics
Measurement ranges Voltage: 150 V to 600 V, 3 ranges
Current: 5 A to 5 kA, 8 ranges (use clamp sensor)
Power: 750 W to 9 MW, 16 combination patterns
Basic accuracy Voltage: ±0.2 % rdg. ±0.1 % f.s.
Current:±0.2 % rdg. ±0.1 % f.s. + Clamp accuracy (active power, at 45 to 66 Hz)
Clamp sensor accuracy 9660 (100 A AC): ±0.5 % rdg. ±0.3 % f.s.
9661 (500 A AC): ±0.5 % rdg. ±0.11 % f.s.
9669 (1000 A AC): ±1.2 % rdg. ±0.11 % f.s.
9667 (5000 A AC, flexible): ±2.2 % rdg. ±0.4 % f.s.
Frequency characteristics Fundamental waveforms up to 40th harmonic ±3 % f.s. + measurement accuracy (of a 45 to 66 Hz fundamental waveform)
Data storage Internal memory: 1 MB
Flash Card: Up to 528 MB
Other functions RS-232C, External I/O (Option; D/A output)
Display update rate Approx. 0.5 time/second
Power supply 100 to 240 V AC, 50/60 Hz
Dimensions, mass 210 mm (8.27 in) W " 160 mm (6.30 in) H " 60 mm (2.36 in) D, 1.2 kg (42.3 oz)
Accessories 9438-03 Voltage cord set, Input cord label, Operation manual, Power cord
