Keysight 44478B Multiplexer Module, DC - 1.3 GHz

HP/Agilent 4447B Dual Multiplexer Module 1.3GHz, 75 ohms
Enlarge Image
Keysight 44478B
Request Quote Print Page
Datasheet

The Keysight 44478B Multiplexer Module is an ideal choice for broadband switching of high-frequency or fast pulse signals. Dual 1-to-4 multiplexers provide bi-directional switching of signals from DC to 1.3GHz. High-channel isolation (>55 dB at 1 GHz) assures quality dynamic-range measurements using spectrum, network, or distortion analyzers. Each 1-to-4 multiplexer consists of seven relays in a "tree" structure, which provides high isolation and low VSWR (voltage standing wave ratio). All the connectors on the modules edge are female BNC for ease of wiring. Off-channels can be terminated in resistors to maintain proper operation of DUT circuitry. Simply plug a 50/75 ohms SMB type resistive termination onto the on-board male SMB connector provided for each channel.



Features:

  • Insertion loss less than 1.9dB at 1.3GHz
  • Switching up to 1A, 24W or 24VA
  • Maximum Voltage: 42V, DC+AC peak
  • Maximum Scan Rate: 43 Chans/sec
  • Maximum Power:
  • Per channel: 24W, 24VA or 44dBm, Characteristic Impedance: 75 ohms
  • Maximum Current: 1A



Specifications:

Input Characteristics
Maximum Scan Rate 43 Chans./sec
Maximum Voltage 42 V, DC + AC peak
Maximum Current 1 A
Maximum Power
(Per channel)
24 W, 24 VA or 44 dBm
Characteristic Impedance 75 Ω
DC Performance
Thermal Offset <6 μV (<2 μV, Typ.)
Initial Closed
Channel Resistance
<1 Ω
Insulation Resistance
(between terminals)<(25 °C, 40% RH)
>1010 Ω
Capacitance
Center-Center <0.006 pF
Center-Shield <60 pF
Rise Time <300 psec
Signal Delay <3 nsec
AC Performance
Insertion Loss
≤(40 °C, 95% RH)
10 MHz <0.3 dB
100 MHz <0.7 dB
500 MHz <1.5 dB
1.3 GHz <3.0 dB
≤(25 °C, 40% RH) 10 MHz <0.2 dB
100 MHz <0.5 dB
500 MHz <1.1 dB
1.3 GHz <1.9 dB
Crosstalk
Channel-Channel, Channel-Common
10 MHz <-90 dB
100 MHz <-80 dB
500 MHz <-65 dB
1.3 GHz <-55 dB
Group-Group, Module-Module 10 MHz <-90 dB
100 MHz <-80 dB
500 MHz <-70 dB
1.3 GHz <-60 dB
VSWR 10 MHz <1.20
100 MHz <1.25
500 MHz <1.35
1.3 GHz <1.55
