Pacific Power Source 360ASX 6 kVA Power Source

Pacific Power Source 360ASX Power Source | 6 kVA
Enlarge Image
Pacific Power 360ASX
Request Quote Print Page
Manual Datasheet Brochure

The ASX Series Power Source is equipped with a powerfuly microcontroller to create a fully integrated test system. It supplies a variety of power conditions to the device under test and meters/analyzes all output performance parameters.

Document of capable IEC Standards


  • Model 360ASX
  • Rated Power VA) 6000
  • Output Form 1Ø / 3Ø
  • Form Volts-Max(Vrms)135/270 135 (Vl-N)
  • Amps (Arms) 48/16 16 per Ø
  • Amps(Apeak) 210/70 70 per Ø
  • Input Power Form 3Ø
  • Panel Height (U) 5
  • Weight (LBS./KG.) 180/82



Frequency/Voltage Conversion

The ASX Series is an excellent source of stable AC voltage over the frequency range of 15 to 1,200 Hz. The output frequency is quartz-crystal stabilized. Output voltages up to 600 VAC are provided.



Phase Conversion

With the ability to provide singe and three-phase outputs, the ASX Series is the perfect choice to provide 1 Phase to 3 Phase or 3 Phase to 1 Phase conversion.


Features:


  • 22 Waveform Library – Arbitrary Waveform Generator
  • 15 to 1,200 Hz Operation – 5,000 Hz Bandwidth
  • Precision Voltage Programming – 0.05% with CSC engaged
  • Precision TRUE-RMS metering of volts, amps, and power for displays and reporting
  • RS-232 Interface with SCPI
  • 1 Phase/3 Phase Switch Selectable Output from front panel or bus command
  • 99 stored programs for both static and dynamic Transient Testing

Options:


  • GPIB (IEEE-488.2) Interface with SCPI
  • Programmable Output Impedance
  • Harmonic Analysis (FFT) and Waveform Synthesis
  • Load Surge Analysis and Waveform Capture
  • LabVIEW for Windows™ and LabWindows™ Instrument Drivers
  • Wide range of Output Magnetics for world-wide testing.
