The Associated Research 7550DT has been replaced by newer models.
Click here for replacement models
The Associated Research 7550DT is designed to meet safety agency standards such as UL, CSA, IEC, VDE, TV and the European Norms including the Low Voltage Directive 73/23/EEC.
The first complete multi-function systems HypotULTRA®II combines the three most common dielectric safety tests (AC Hipot, DC Hipot & IR test) required by agencies such as UL, CSA, IEC, VDE, TV, BABT and others into a single 19 rack mount cabinet which takes up less rack space and allows for testing through a single DUT (Device Under Test) connection. All the functions of the instruments can be programmed over a GPIB, RS-232 or printer interface which makes them adaptable to any automated production environment. The Associated Research 7550DT offers the option of a built-in 8 port scanner and an interface to control up to 2 external 8 port scanners. These optional scanner configurations are ideal for multipoint testing of a single item or multiple product testing. The high voltage outputs of either the internal or external scanner can be set as high, low or off. A front panel display shows the status of each scanner output port.
Specifications
Input |
Voltage |
115/230 VAC ±15%, Single Phase, User selectable |
Frequency |
47 Hz - 63 Hz |
Fuse |
6.3 Amp 250 V Slo-Blo |
Dielectric Withstand Test Mode |
Output Rating |
5 kVAC @ 40 mA, 6 kV DC @ 10 mA |
Output Adjustment |
Range: |
0 - 5 kV AV or 0 - 6 kV DC |
Resolution: |
1 volt/steps |
Accuracy: |
±(2% of Setting + 5 volts) |
Ramp Hi (DC) |
Range: 12 mA peak max., ON/OFF selectable |
Charge Lo (DC) |
Range: 0.0 - 350 μA or auto set |
Hi-Limit (AC) |
Range: |
0.00 - 40.00 mA |
Resolution: |
0.01 mA/steps |
Accuracy: |
±(2% of setting + 2 counts) |
Hi-Limit (DC) |
Range: |
0 - 9999 μA |
Resolution: |
1 μA/steps |
Accuracy: |
±(2% of setting + 2 counts) |
Lo-Limit (AC) |
Range: |
0.000 mA - 9.999 mA |
Resolution: |
0.01 mA/steps |
Accuracy: |
±(2% of setting + 2 counts) |
Lo-Limit (DC) |
Range: |
0.0 - 999.9 μA |
Resolution: |
0.1 μA/steps |
Accuracy: |
±(2% of setting + 2 counts) |
Arc Detection |
Range: 1 - 9 |
Failure Detector |
Audible and Visual |
DC Output Ripple |
≤ 4% Ripple RMS at 6 kV DC @ 3.5 mA, Resistive Load |
AC Output Waveform |
Sine Wave, Crest Factor = 1.3 - 1.5 |
Output Frequency |
Range: |
60 Hz or 50 Hz, User Selectable |
Accuracy: |
±1% |
Output Regulation |
±(1% of setting + 5 volts) from no load to full load |
Dwell Timer |
Range: |
0, 0.3 - 999.9 sec. (0 = Constant) |
Resolution: |
0.1 sec. increments |
Accuracy: |
±(0.1% + 0.05 sec.) |
Ramp Timer |
Range: |
AC 0.1 - 999.9 sec. |
Resolution: |
0.1 sec. increments |
Accuracy: |
±(0.1% + 0.05 sec.) |
Ground Continuity |
Current: |
DC 0.1 A ±0.01 A, fixed |
Max. ground resistance: |
1Ω ±0.1Ω, fixed |
Insulation Resistance Test Mode |
Output Voltage |
Range: |
100 - 1000 VDC |
Resolution: |
1 volt/steps |
Accuracy: |
±(2% of setting + 2 volts) |
Short Circuit Current |
Max.: 12 mA peak |
Voltage Display |
Range: |
0 - 1000 V |
Resolution: |
1 volt/steps |
Accuracy: |
±(2% of setting + 2 volts) |
Charge Lo |
Range: 0.000 - 3.500 μA or Auto Set |
Hi-Limit |
Range: 0 - 9999 MΩ (0 = off) |
Lo-Limit |
Range: 1 - 9999 MΩ |
Delay Timer |
Range: |
0, 0.5 - 999.9 sec. (0 = Constant) |
Resolution: |
0.1 sec./steps |
Accuracy: |
±(0.1% + 0.05 sec.) |
