| Measuring range |
X axis: .69" (17.5mm) or .22" (5.6mm)
Z axis: 14200 µin (-7900µin~+6300µin) / 360µm (-200µm ~ +160µm) |
| Measuring speed |
0.01, 0.02, 0.03 in/s (0.25mm/s, 0.5mm/s, 0.75mm/s)
Returning: 1mm/s |
| Measuring force / Stylus tip |
0.75mN type: 0.75mN / 2µmR 60°, 4mN type: 4mN / 5µmR 90° |
| Skid force |
Less than 400mN |
| Sampling length |
0.003, 0.01, 0.03, .1 " (0.08 , 0.25 , 0.8 , 2.5mm |
| Dimensions (W x D x H) |
2.05 x 2.6" x 6.3" (52.1×65.8×160mm) |
| Weight |
1.1 lb. (500 g) (Display unit + Drive unit + Standard detector) |
