Taylor Hobson Surtronic S-128 Surface Roughness Tester

Larger

Categories

Surface Roughness Testers

Documents

Datasheet

The Taylor Hobson Surtronic S-128 Surface Roughness Tester is a powerful tool that offers detailed roughness measurements in a portable device. The Surtronic S-128 roughness tester is a preferred device for professionals in the automotive and aerospace industries as it works quickly, with a measuring speed of 1 mm per second. Despite its small size, only weighing 1.1 lb, this surface roughness tester easily measures much larger surfaces thanks to a 50mm stylus lift and 70mm stylus reach.

The Taylor Hobson Surtronic S-128 Surface Roughness Tester also uses a balance of detailed measurements with a simple set up to help experienced and new users. Measurements come with a detailed graph on a 4.3" touchscreen display, showing a possible 7 parameters on every page along with all measurement settings. Making use of InstantOn technology, the Surtonic S-128 is ideal for quick measurements, producing results in a few seconds with the press of a single button.

The Taylor Hobson Surtronic S-128 Surface Roughness Tester is a part of the Taylor Hobson Surtronic S-100 Series.

Specifications
Features
Applications
Options
Accessories
Standards
Videos

Gauge Specifications
Range	400 μm / 100 μm / 10 μm
Resolution	50 nm / 10 nm / 5 nm
Noise floor (Ra)	150 nm / 100 nm / 50 nm
Repeatability (Ra)	0.5% of value + noise
Force	150 - 300 mg

General Specifications
Calibration Process	Automated software calibration routine
Analysis Filter Cut-off	0.25 mm / 0.8 mm / 2.5 mm
Analysis Filter Type	2CR / Gaussian
Evaluation Length	0.25 mm - 25.0 mm (0.01 in - 1.00 in)
Measuring Speed	1 mm/sec (0.04 in/sec)
Returning Speed	1.5 mm/sec (0.06 in/sec)
