Pacific Power 3120-ASX 12kVA Programmable AC Power Source

Rent Pacific Power Source 3120-ASX 12kVA Power Source
Enlarge Image
Pacific Power 3120-ASX
Request Quote Print Page
Datasheet
The Pacific Power 3120-ASX is Pacific’s latest addition to its line of Manual and Programmable AC Power Sources. Power Conversion within the ASX Series is achieved by high frequency pulse width modulation, resulting in cool, quiet and efficient operation.

The 3120-ASX is ideal for AC test, frequency conversion, laboratory and bench-power applications.

AC TEST POWER
The 3120-ASX is equipped with the UPC Programmable Controller, a powerful micro-controller used to create a fully integrated test system. It supplies a variety of power conditions to the device under test and meters/analyzes all output performance parameters.

FREQUENCY/VOLTAGE CONVERSION
The 3120-ASX is an excellent source of stable AC Voltage over the frequency range of 15 to 1,200Hz. The output frequency is quartz-crystal stabilized. Output voltages up to 600V are available.

PHASE CONVERSION
With the ability to provide single and three-phase outputs, the 3120ASX is the perfect choice to provide three-phase input to split (two-phase) or single-phase output power conversion.

Options:
  • GPIB (IEEE-488.2) Interface with SCPI
  • Programmable Output Impedance
  • Harmonic Analysis (FFT) and Waveform Synthesis
  • Peak Inrush Capture and Waveform Analysis
  • LabVIEW for Windows™ and LabWindows™ Instrument Drivers
  • UPC Manager Software Suite
  • Wide range of Output Magnetics for worldwide testing


Features:

  • 22 Waveform Library – Arbitrary Waveform Generator
  • 15 to 1,200Hz Operation – 5,000 Hz Small Signal Bandwidth
  • Precision Voltage Programming – 0.05% with Continuous Self-Calibration (CSC) engaged
  • Precision True-RMS metering of volts, amps, and power for displays and reporting
  • RS-232 interface with SCPI
  • 1 phase/3 phase Switch Selectable Output from front panel or bus command
  • 99 steady state programs with associated transients for static and dynamic test applications


Specifications:

OUTPUT FREQUENCY 15 to 1,200Hz Full Power
LINE REGULATION 0.1% Max For ±10% line change
LOAD REGULATION 0.25% 15 to 400Hz
0.50% 400 to 1,200Hz
With external sense enabled
Improves to less than 0.1% with
Continuous Self-Calibration enabled
OUTPUT DISTORTION 0.25% THDAVG 15 to 200Hz
0.50% THDAVG 200 to 1,200Hz
RIPPLE AND NOISE -66dB
RESPONSE TIME 60 microseconds typical, 10-90% load step
