NH Research 9300 High-Voltage Battery Test System
- Scalable to 2.4MW / 8000A
- Max Current @ 600V: 333A
- Current @ 1200V: ±167A
Keysight SL1215A Scienlab Regenerative AC / Grid Simulator | 130 / 65 A, 90 kW / 135 kVA
- Dual-range high-power AC and DC
- AC (1, 2, or 3 Φ) and DC power source
- Full specs, no transformer required
Magna-Power TSD125-120 Programmable DC Power Supplies
- Power level: 15 kW
- AC Input Voltage: 3Φ, 208 Vac
- Voltage ripple: 100 mVrms
ITECH IT6018C-1500-40 Power Supply | 1500 V
- Bi-directional source and regenerative sink
- Standard built-in USB/CAN/LAN/digital IO interface, optional GPIB/analog & RS232
- Full protections: support OVP, ±OCP, ±OPP, OTP, power down protection, anti-islanding protection
Regatron TopCon Quadro Power Supply | TC.P.32.1000.480.S | 32 kW, 1000 VDC
- Constant voltage (0 – 100 %), constant current (0 – 100 %) and constant power operation (5 – 100%) with automatic and fast crossover and mode indication, internal resistance
- Finely graduated product line: 52, 65, 100, 130, 200, 400, 500, 600, 800, 1000, 1200 VDC; power categories of 10, 16, 20 and 32 kW are available for each nominal output voltage
- Optional extras and accessories complete the product line of power supply units
Chroma 61860 Regenerative Grid Simulator | 60 kVA
- Power rating up to 300 kVA, single or three-phase output
- Full 4 quadrant, fully regenerative up to 100% of output current rating
- Specifically designed for PV inverter, Smart Grid, and EV related test applications
ITECH IT79165-350-990 Regenerative Grid Simulator
- Voltage: 350V
- Current: 990A
- Power: 165kVA
Pacific Power 3210AGX | AC & DC Load/Power Supply | 21 kVA
- 15 - 1200 Hz
- 1 Phase mode 125 Arms / 62.5Adc
- 0-350 Vac / 0-500 Vdc
Chroma 62180D-600 Bidirectional DC Power Supply | 600 V, 18 kW
- Voltage rating of 120 to 600 V
- Current rating of 0 to 120 A
- Power rating of 18 kW
Pacific Power 3550AZX Regenerative AC & DC Power Source
- 55 kVA
- 55 kW
- 3 Phase
Magna-Power TSD1500-66.4 DC Programmable Power Supply
- Maximum voltage: 1500 Vdc
- Maximum current: 66.4 Adc
- Efficiency: 92%
NH Research (NI) 4800 Bidirectional Power Supply
- Fully integrated battery cycler: built-in isolation contactor relays, pre-charge circuit, reverse polarity checker
- Voltage models from 80 VDC
- Modular and scalable power
Chroma 63804 AC/DC Electronic Load | 350 V, 45 A, 4500 W
- Parallel / 3-phase function
- Constant & rectified load modes for AC loading
- Analog voltage & current monitor
CA Instruments BPS75 AC Power Supply
- Output: 75kVA, 0-150/300V, 3ph
- Frequency Range: 16 - 820Hz
- Input Power: 208/480VAC, 3ph
Chroma 62180D-1800 Bidirectional DC Power Supply
- Two-quadrant operation: source and load functions
- High power density: 18 kW in 3 U
- Easy master/slave parallel & series, 1 operation up to 180 kW
Megger Torkel 950 Battery Load Unit
- Display range: 0.0 to 2999.0 A
- Basic inaccuracy: ±(0.5% of reading +0.1 A)
- Resolution: 0.1 A
Keysight RP7983A Regenerative DC Power Source | 2000 V, 30 kW
- Regenerative Power System PV Mode: 2000 V, ± 30 A, 30 kW, 400/480 VAC
- Operate in two-quadrant mode as power source and regenerative electronic load
- Maximize throughput with fast output speed and sub-millisecond command-processing time
NH Research 4760 High Voltage Electronic DC Load | 600 V, 300 A
- 600 Volts, 300 Amps - Paralleling capability up to 1800 Amps or 36 kW
- 18 Voltage, Current, Power and Timing Measurements
- Complex load profile playback
Chroma 61812 Regenerative Grid Simulator | 12 kVA, 0 – 350 V
- High power density 12 kVA in 3UH
- Intuitive touch panel interface
- User selectable phase (single or 3)
Chroma 61830 Regenerative Grid Simulator | 30 kVA
- Power rating: 30 kVA, 45 kVA, 60 KVA, 105 kVA up to 630 kVA
- User selectable single phase or three phase output
- Harmonics, inter-harmonics waveform synthesizer
Chroma 63206A-600-420 DC Load | 600 V, 420 A
- 600 V and 6 kW
- High precision and accuracy
- Input Resistance: 1 MΩ
Preen AFV-PLUS-33200 AC Power Source
- 200 kVA output power
- Voltage output: 300V
- Output frequency: standard 45 - 65Hz
Magna-Power MTD600-240/480 DC Power Supply
- Industry leading power density Rack-mount space is always at a premium. Magna- Power Electronics power supplies are continuously refined with new technology and devices to drive down size and
- Rack-mount space is always at a premium. Magna- Power Electronics power supplies are continuously refined with new technology and devices to drive down size and increase power density.
- High accuracy programming ±0.075% full scale programming accuracy on all models and programming interfaces.
Chroma 63209 DC Electronic Load
- 15 kW
- 0 - 80 V
- Dynamic loading: <20 kHz
_1.png)
Megger Torkel 860 Battery Bank Load Tester
- Batteries can be tested "in service"
- Unit adjusts to include load currents in the test parameters
- User adjustable alarm and shutdown points to avoid excessive discharge
