| Model |
SM50 |
| Internal storage |
4 GB (at least 3.8 GB available for storing measurement data) |
| Use on a single charge |
Approx. 4-6 hours (depending on intensity of use) |
Linear range of electronics
(combined ranges) |
>110 dB |
Linear measuring range
(with included microphone) |
30 to 122 dB |
| Octave resolution (for real-time analyzer) |
1/1, 1/3, 1/6, & 1/12 |
| Standards |
Fully compliant with IEC-60268-16 Rev 4 (2011) & Rev 5 (2020)
Type 2 / Class 2
SPL measurements compliant with ANSI S1.4 & IEC-61762-1:2014
RTA filter specs exceed class 1 requirements (IEC-61260:2014) |
| Display |
Full-color 3.2” LCD touch screen |
