Keysight N9310A RF Signal Generator

Need Help? Call (800) 404-2832ATEC AssuranceWorldwide Delivery
N9310A RF Signal Generator
Enlarge Image
N9310A RF Signal Generator N9310A RF Signal Generator
Keysight N9310A
Request Quote Print Page
Manual Accessory Kit
The Keysight N9310A RF Signal Generator is ideal for electronic manufacturing test for modern consumer products like cordless phones, digital radios, GPS modules, RFIDs and wireless LAN devices. It is very easy to operate. The N9310A generates common RF signals from 9 kHz up to 3 GHz. With its built-in analog modulation capabilities, it can generate modulated AM, FM, ├śM and pulse signal easily. Adding optional analog IQ input capability can generate complex IQ modulated signals such as GSM, CDMA and OFDM signals from custom IQ inputs. The N9310A is the perfect signal generator for many consumer goods testing applications.
Keysight N9310A Features
  • 9 kHz to 3 GHz CW output, 20 Hz to 80 kHz low frequency (LF) output
  • -127 to +13 dBm output level range (maximum +20 dBm settable)
  • -95 dBc/Hz SSB phase noise
  • Extensive analog modulation: AM, FM, Phase, and Pulse modulation
  • Optional IQ modulator, 40 MHz bandwidth
  • Intuitive GUI offering 11 languages
  • Standard USB connectivity for test automation and memory stick support
  • SCPI command set for remote control
