| Frequency Range |
100 kHz ... 2.7 GHz (w/o power amplifier) |
| 47 MHz ... 862 MHz (w/ power amplifier) |
| Frequency Resolution |
1 Hz |
| Level |
–110 dBm ... +15 dBm (w/o power amplifier) |
| +27 dBm, adjustable from 0 dB - 30 dB (w/ power amplifier) |
| SSB Phase Noise |
at 300 MHz and 20 kHz carrier offset |
< –115 dBc (1 Hz) |
| Broadband Noise |
> 10 MHz |
< –135 dBc (1 Hz) |
| Digital Real-time Modulation Systems |
Terrestrial, Cable, Satellite, Mobile, Digital Audio Broadcasting (see datasheet) |
| Signal-to-noise Ratio |
–30 dB ... +60 dB |
