OMICRON CPC 100 Multi-functional Primary Test System

Add to Quote

Enlarge Image

OMICRON CPC 100

Request Quote Print Page Email Page

Brochure

Electrical tests on transformers, current transformers, voltage transformers, grounding systems, lines and cables, and circuit breakers can be performed with the OMICRON CPC 100. The patented test system replaces several individual testing devices and offers new, innovative testing methods. The CPC 100 is the base for multiple accessories. These facilitate further applications, such as tan delta measurements, as well as line and ground impedance measurements

Features:

Up to 800 A or 2000 V with up to 5 kVA over a frequency range of 15-400 Hz or 400 A DC
Excellent interference suppression facilitates measurement of small signals
Easy to transport (just 29kg) - Ideal for on-site testing
Testing templates, automatically generated testing procedures and test reports
Up to 2000 A or 12 kV through use of current or voltage amplifiers

Applications:

Current transformers (CT)

Ratio, burden and polarity
Phase and magnitude error
Excitation curve
Winding resistance
Secondary burden
Dielectric withstand voltage
(2 kV AC)
CT circuit continuity

Voltage transformers (VT)

Ratio, burden and polarity
Phase and magnitude error
Excitation curve
Winding resistance
Secondary burden
Dielectric withstand voltage
(2 kV AC)
VT circuit continuity

Transformers

Ratio
Winding resistance
Tap changer test
Excitation current
Short circuit impedance

Lines and cables

Impedance (k-factor)
Transformer coupling

Grounding systems

Ground impedance
Step and touch voltages

Circuit breakers

Contact resistance

Accessories:

Extension with CP TD1: Capacitance/dissipation factor testing (tan delta), insulation diagnostics
Extension with CP CB2: Current amplifier for up to 2000 A
Extension with CP CU1: Testing line impedances, ground impedances and k-factor
Extension with CP SB1: Fully automated testing of three-phase transformers
Extension with CP CR500: Compensating Reactor
Extension with CP TC12: 12 kV Oil Test Cell
Extension with CPOL: Polarity Checker
Extension with CP AL1: Fast Fourier Transformation Voltmeter
Extension with CP RC: Resonance Circuit
Extension with CP DB1: Transformer Discharge Box
