HV Diagnostics HVA68TD VLF/DC Hipot Tester
- 0 - 68 kV peak, 48 kV RMS @ 88 mA
- For testing cables rated to 46 kV
- Integrated tan delta testing
OMICRON CPC 100 Multi-functional Primary Test System
- Max Output Current (AC): 800A
- Max Output Current (DC): 400A
- Input Voltage: 300V
HV Diagnostics HVA60 VLF & DC Hipot Tester
- 62 kV peak, 44 kV RMS @ 40 mA
- For testing cables rated to 35 kV
- Input voltage: 110 - 240 VAC ±10% (50/60Hz)
OMICRON CP TD1 Capacitance & Tan Delta Test Unit
- Compact and rugged all-in-one test set
- Wider frequency range for more sensitivity (15 Hz – 400 Hz)
- Testing at variable frequencies for better condition diagnosis
High Voltage PTS-200 Portable DC Test Set
- 0 – 200kV DC @ 5mA
- Negative Polarity
- Positive Ground
Hipotronics 840PL | 40kV
- DC hipot test up to 40kV, 10mA
- Lightweight, rugged design for field use (57 lbs / 25.8kg)
- Measures output voltage, leakage current, insulation resistance (IR), and polarization index (PI)
Doble M7100
- 0.250–12 kV RMS
- 15–500 Hz Range
- ±0.5% Accuracy
High Voltage Inc. DBT Series
- 15kV - 300kV DC
- Benchtop DC Hipot Test System
- Adjustable Test Currents up to 10mA
Vitrek V60 Programmable AC-DC Hipot / Electrical Safety Tester Series
- Fully automated testing at the touch of a button or via RS232 & PLC control (GPIB optional)
- Three models to choose from - select the functions you need to get the job done
- Available Quicktest™ test automation software for your PC
Megger TRAX Transformer and Substation Test System
- Current Output: 200A AC (TRAX 219)
- Current Output: 200A AC (TRAX 220)
- Current Output: 800A AC (TRAX 280)
OMICRON TESTRANO 600 Three-Phase Power Transformer Test System
- Powerful device (3x 33 A DC and 400 V AC)
- One setup for multiple tests, less reconnecting
- Three times faster testing
OMICRON TANDO 700 Dissipation Power Factor & Capacitance Test Set
- High voltage potential
- Extendable range
- Flexible use in test labs and in the field
High Voltage PTS-80 DC Hipot Megohmmeter 80 KVDC
- Two range voltmeter
- Five range current meter with a low range with resolution to 10 nanoamperes
- Megohm readings at any output voltage
High Voltage PTS-75 DC Hipot/Megohmmeter Tester 75 kV
- 0 – 75kV DC @ 10mA
- Negative Polarity
- Positive Ground
High Voltage Inc. PTS-130 | 130 kV
- 0 – 130kV DC @ 10mA
- Negative Polarity
- Positive Ground
High Voltage PTS-100 | 100 kVA, 10 mA
- 0 – 100kV DC @ 10mA
- Negative Polarity
- Positive Ground
Phenix Technologies PAD-10-25 AC/DC Hipot Megohmmeter
- 0 - 10kV AC @ 10mA / 0 - 25kV DC @ 5mA
- Negative Output
- Positive Ground
Tettex MIDAS 2881 Mobile Insulation Diagnosis & Analysing System
- Dissipation Factor (tanδ) and Power Factor (cosΦ )
- Short Circuit Impedance and Excitation Current
- Additional measuring capabilities like Capacitance, Quality Factor, Frequency, Voltage, Current, Power, Losses, Impedance, Inductance, Reactance, Spectrum Analyzer, Digital Scope and Data Logger
Megger VAX020 High Voltage Amplifier
- Separate high voltage amplifier enables capacitance and dissipation factor measurements at 2 kV test voltage
- True and proven DFR/FDS technology for highest performance
- Large frequency range, DC to 1 kHz
Doble M4100 Power Factor Insulation Analyzer
- 47 - 63 Hz
- 25 V - 12 kV Source Output
- Typical Accuracy: ± 0.005%
Doble M4000 Power Factor/Tan-Delta Instrument
- Totally eliminates substation signal interference with Doble's patented Line Frequency Modulation technology
- Generates its own clean test signal for the most reliable and repeatable results
- The highest power to better replicate in service condition
Megger IDAX300 Insulation Diagnostic Analyzer
- Fast and accurate moisture assessment in power transformers
- Well proven technology; IDAX300 units have been in field use for more than 10 years
- Reliable results at any temperature
HV Diagnostics HVA34TD VLF/DC Hipot Tester
- Easy-to-use operator interface
- Integrated Tan Delta measurement system
- Performs automatic and advanced tests
HV Diagnostics HVA28TD VLF/DC Hipot Tester
- 5-in-1 universal high voltage and diagnostic testing system
- Integrated Tan Delta measurement system
- Output current of 0 to 20 mA
HV Diagnostics HVA 30 4 in 1 Universal High Voltage VLF and DC Hipot Tester
- Smallest, lightest, most advanced universal high voltage test instrument available.
- VLF (0.1Hz), DC, Cable Fault Conditioning (Burning), and Sheath/Jacket Testing modes all included.
- Fully Automatic or manual cable test sequences
