EM Test

EM Test UCS 200N Automotive Transient Generator for ISO 7637

  Tech Support
(800) 404-2832
ATEC Assurance With Every
Rental
    Worldwide
Delivery
EM Test UCS 200N Automotive Transient Generator for ISO 7637 Larger
Categories
  • Automotive Transient Test Systems
    Automotive Transient Test Systems
Documents
  • Datasheet
  • Supplemental Document
  • Print
  • Email
The EM Test UCS 200N Ultra-Compact Simulator series combines the power of a micropulse simulator, a recoupling network, and an EFT/Burst simulator into one device. Meeting international and car manufacturer specifications on a global scale, the EM Test UCS 200N Ultra-Compact Simulator series is an impressive device. The built-in coupling network on the UCS 200N can be used and controlled by any unit of the series. Additionally, the built-in coupling network varies from up to 200A depending on the model. Functions for the EM Test UCS 200N include automotive and telecom applications. The EM Test UCS 200 is intuitive with a front panel menu and function keys that enable precise user-programmable test routines.
  • Specifications
  • Features
  • Applications
  • Options
  • Accessories
  • Standards
  • Videos
Features
  • Built-in EFT/Burst generator module
  • Built-in Micropulse generator module (ISO 7637, JASO, SAE and NISSAN)
  • Built-in coupling network 60V, up to 200A
  • Built-in battery switch
  • Overcurrent protection
  • USB and GPIB-Bus
Specifications
UCS 200N MODELS
UCS 200N50 Built-in coupling/decoupling network, 60V/50A, 100A@500ms
UCS 200N100 Built-in coupling/decoupling network, 60V/100A, 150A@500ms
UCS 200N150 Built-in coupling/decoupling network, 60V/150A
UCS 200N200 Built-in coupling/decoupling network, 60V/200A
INPUT
DUT supply +/- DC voltage from VDS 200N or any other DC supply
Pulse 5, 7 From one LD 200N
OUTPUT
DUT supply +/- Central DUT output
Coaxial output port To connect the capacitive coupling clamp as per ISO 7637-3:2007
EFT/BURST MODULE FOR TEST PULSES 3A/3B As per ISO 7637-2
Test voltage 25V - 1,000V ± 10%
Rise time 5ns ± 1.5ns
Pulse duration 150ns ± 45ns
Verification As per Annex C of ISO 7637-2:2011 into 50ohm and 1,000ohm load
Source impedance Zq = 50ohm
Polarity Positive/negative (Pulse 3b/3a)
TRIGGER CIRCUIT
Trigger of bursts Automatic, manual, external
Burst duration T4 = 0.1ms - 999.9ms
Repetition rate T5 = 10ms - 9,999ms
Spike frequency f = 0.1kHz - 200kHz
Test duration T = 0:01min - 999:59min
T > 999:59min --> endless
OUTPUTS
Direct Via 50ohm-coaxial connector (for tests using e.g. a capacitive coupling clamp)
Coupling mode To the + battery line (supply lines)
CRO trigger 5V trigger signal for oscilloscope
TEST ROUTINES
Quick Start On-line adjustable parameters, easy-to-use
Standard Test routines As per ISO 7637-2:2011, Levels 1 - 4
User Test routines Random burst release
Change voltage after T
Change frequency after T
DIMENSIONS AND WEIGHT
UCS 200N50 19"/3HU, approx. 20kg
UCS 200N100 19"/6HU, approx. 30kg
UCS 200N150 19"/9HU, approx. 35kg
UCS 200N200 19"/9HU, approx. 35kg
Supply voltage 115/230V +10/-15%
Fuses 2 x T 2AT (230V) or 2 x T 4AT (115V)
Applications
Learn About EMC Testing

  • Automotive
  • Telecom
Options
Accessories
Standards
Media

RELATED PRODUCTS

EM Test UCS 200N50 Automotive Transient Generator
EM Test UCS 200N50 Automotive Transient Generator
EM Test LD 200N Load Dump Generator for ISO 7637
EM Test LD 200N Load Dump Generator for ISO 7637
Hilo-Test CAR Test System 14
Hilo-Test CAR Test System 14
Hilo-Test CAR PG 2804 Load Dump Generator
Hilo-Test CAR PG 2804 Load Dump Generator
Teseq NSG 5500 Automotive Transient Immunity Tester for ISO 7637
Teseq NSG 5500 Automotive Transient Immunity Tester for ISO 7637
EM Test VDS 200N100 Voltage Drop Simulator 60 V, 100 A
EM Test VDS 200N100 Voltage Drop Simulator 60 V, 100 A
EM Test PFM 200N100.1 Automotive Power Fail Simulator
EM Test PFM 200N100.1 Automotive Power Fail Simulator
Teseq PA 5740 Power Amplifier/Battery Simulator
Teseq PA 5740 Power Amplifier/Battery Simulator
Teseq NSG5200 Automotive Transient Test System
Teseq NSG5200 Automotive Transient Test System
EM Test Autowave Arbitrary Generator
EM Test Autowave Arbitrary Generator
Teseq NSG 5600 Automotive Transient Generator
Teseq NSG 5600 Automotive Transient Generator
EM Test PFS 200N Series Automotive Power Fail Simulator
EM Test PFS 200N Series Automotive Power Fail Simulator
EM Test Automotive Transient Emission Set 100 kHz - 125 MHz
EM Test Automotive Transient Emission Set 100 kHz - 125 MHz
EM Test RCB 200N1 Transient Immunity Test Generator for FORD EMC-CS-2009.1
EM Test RCB 200N1 Transient Immunity Test Generator for FORD EMC-CS-2009.1
Teseq NSG 5071 Inducitive Switch Transient Test Circuit
Teseq NSG 5071 Inducitive Switch Transient Test Circuit
Teseq CDN 500 ISO 7637-3 Capacitive Coupling Clamp
Teseq CDN 500 ISO 7637-3 Capacitive Coupling Clamp
AE Techron 3110 Standards Waveform Generator
AE Techron 3110 Standards Waveform Generator
AE Techron 3110A Standards Waveform Generator
AE Techron 3110A Standards Waveform Generator
AE Techron CIS-25 Conducted/Induced Susceptibility EMC Testing Kit
AE Techron CIS-25 Conducted/Induced Susceptibility EMC Testing Kit
AE Techron DSR 100-200 Battery Simulator
AE Techron DSR 100-200 Battery Simulator
BOLAB 100-TS Series | DC – 200 kHz, 400 W – 18000 W
BOLAB 100-TS Series | DC – 200 kHz, 400 W – 18000 W
BOLAB AN-ABCD-300-C10 Artificial Network System | 1000 V, 300 A
BOLAB AN-ABCD-300-C10 Artificial Network System | 1000 V, 300 A
Bolab AN-ABCD-60 Artificial Network System
Bolab AN-ABCD-60 Artificial Network System | 1000 V, 60 A
BOLAB Systems BLS-130-70N-TS 4-Quadrant Voltage Amplifier
BOLAB Systems BLS-130-70N-TS 4-Quadrant Voltage Amplifier
EM Test ISO Automotive Rack
EM Test ISO Automotive Rack
  • Certified ISO 9001
  • A2LA
REP PORTAL Terms & Conditions About About ATEC Blog Media News FAQs Forms Careers

© 2023 Advanced Test Equipment Corp. All Rights Reserved.

Privacy Notice Terms of Use Site Map Linecards
This site uses cookies, as explained in our cookie policy.
