HP Agilent 3326A Function Generator, DC to 13 MHz

P Agilent 3326A Function Generator, DC to 13 MHz
Enlarge Image
P Agilent 3326A Function Generator, DC to 13 MHz P Agilent 3326A Function Generator, DC to 13 MHz P Agilent 3326A Function Generator, DC to 13 MHz
Request Quote Print Page
Manual Datasheet

Combines two independent synthesizers, flexible modulation and control circuitry into a single, powerful package

  • Provides precise phase offset, two-tone sweep, fast frequency switching, internal modulation, and pulse signals
  • Internal switch selected signal combiner sums both source outputs into a single ultra-low IMD signal source
  • Phase continuous sweeps are available in linear and multielement discrete modes
  • DC offset is available in all modes, and all outputs are floating



Specification Summary

  • Frequency (waveforms are sine, square, pulse, and dc)
    • Range: 0 Hz to 13 MHz
    • Resolution: 1 µHz below 100 kHz, 1 mHz at and above 100 kHz
    • Output Amplitude (sine mode) - Range: 1 mVpp to 10 Vpp in 8 ranges without DC offset
  • Phase Offset (channel A vs B in two-phase mode)
    • Range/Resolution: = 720 degrees range, 0.01 degree resolution
  • Frequency Sweep
    • Sweep Types: linear, discrete (2-63 discrete elements)
    • Sweep Time: 5 ms to 1000 s, Linear or per element



Modes

  • Two-Channel: Channels A and B are independent
  • Two-Phase: Channels A and B are the same frequency, with a calibrated phase difference between them
  • Two-Tone: Channel B frequency must be within 100 kHz of the Channel A frequency
  • Pulse: Channel B is the complement of the Channel A output




Amplitude Modulation

Channel A and Channel B outputs with external modulation or to the Channel A output with internal modulation (Channel B is the modulation source).

  • Waveforms: Sine, square, or pulse (pulse allowed in external only)
  • Carrier Frequency Range: DC to 13 MHz
  • Modulation Frequency Range: DC to 100 kHz
  • Modulation Depth: 0 to 100%




Phase Modulation

Channel A and Channel B outputs with external and synchronous phase modulation, and to the Channel A output with internal phase modulation (Channel B is the modulation source).

  • Waveforms: Sine, square or pulse (pulse allowed in external only)
  • Carrier Frequency Range: DC to 13 MHz
  • Phase Deviation: ±360°
