Tektronix/Sony AWG2020 Arbitrary Waveform Generator

Need Help? Call (800) 404-2832ATEC AssuranceWorldwide Delivery
Rent, Buy, or Lease the Tektronix / Sony AWG2020 Arbitrary Waveform Generator - Advanced Test Equipment Rentals | Call 1-800-404-ATEC(2832) for pricing…
Enlarge Image
Tektronix Test Equipment AWG2020
Request Quote Print Page
AWG2020 Datasheet
The Tektronix AWG2020 Arbitrary Waveform Generator has a record length of 256K, built-in PC-compatible 3.5 in 1.4 MB floppy disk for storage and transfer, DOS-like waveform file management and formula entry of parameters for mathematically precise waveforms. It can operate in continuous, triggered, gated, burst, waveform advance and autostep modes.
  • Opt 02 - Second channel
  • Opt 09 - Digital Signal Processing
Tektronix Test Equipment AWG2020 Features
  • 256K (262, 144 points) record length
  • Built-in PC-compatible 3.5" floppy disk for storage and transfer
  • Includes digital signal processing & second channel
  • Formula entry of parameters for mathematically precise waveforms
Tektronix Test Equipment AWG2020 Specs
  • Frequency Range: 10 Hz - 250 MHz
  • Waveforms: sine, square, pulse, ramp, triangle, arbitrary, & DC
  • Waveform Memory: 256K x 12 bits for waveform data; 256K x 1 bit for Marker 2 data. Waveform: 64 to 256K in multiples of 8 data points.
  • Operating Modes: Continuous, triggered, gated, burst, waveform advance, autostep
  • Dimensions: 362 mm W x 164 mm H x 491 mm L (14.25" x 6.45" x 19.33")
  • Weight: 9.7 kg (21.4 lbs)
