Keysight PXA N9030B Signal Analyzer, Multi-touch, 3 Hz to 50 GHz

Larger

SKU: KEYS-N9030B-PXA

Categories

Spectrum Analyzers

Documents

Datasheet

The Keysight N9030B PXA is a multi-touch signal analyzer that operates over a frequency range of 3 kHz to 50 GHz and an analysis bandwidth of up to 510 MHz. Keysight PXA N9030B analyzers are designed to provide enhanced signal analysis features for complicated and intensive test applications.

The PXA N9030B is especially ideal for high-performance aerospace, defense, and telecommunications test scenarios, particularly in research and development. PXA signal analyzers allow users to test signals over broad bandwidths, increase measurement certainty, and can discover concealed signals by means of noise floor extensions.

Users can choose from a diverse array of options as well, adding sophisticated features like real-time spectrum analysis. Other Keysight N9030B features include visualizing small signals with spurious-free dynamic range, gap-free streaming up to 255 MHz, and transient waveform analysis.

Specifications
Features
Applications
Options
Accessories
Standards
Videos

Specifications

Frequency:	3 Hz to 50 GHz, Mixers to 1.1 THz
Frequency Options:	3.6, 8.4, 13.6, 26.5, 43, 44, 50 GHz, Mixers to 1.1 THz
Maximum Analysis Bandwidth:	510 MHz
Bandwidth Options:	25 standard, 40, 85, 125, 160, 255, 510 MHz
Maximum Real-Time Bandwidth:	510 MHz
Real-Time Bandwidth Options:	85, 160, 255, 510 MHz
DANL @1 GHz:	-171 dBm
Phase Noise @1 GHz (10 kHz offset):	-136 dBc/Hz
Phase Noise @1 GHz (30 kHz offset):	-136 dBc/Hz
Phase Noise @1 GHz (1 MHz offset):	-146 dBc/Hz
Overall Amplitude Accuracy:	±0.19 dB
TOI @1 GHz (3rd Order Intercept):	+22 dBm
Maximum Dynamic Range 3rd Order @1 GHz:	118 dB
Applications-General Purpose:	89600 VSA Software Analog Demodulation MATLAB Noise Figure Phase Noise Pulse Real-Time Spectrum Analysis
Applications-Cellular:	GSM/EDGE LTE/LTE-Advanced W-CDMA/HSPA/HSPA+ NB-IoT
Applications-Wireless Connectivity:	Short Range Communications (ZigBee, Z-Wave) Bluetooth® (BR/EDR/LE4.2/5.0) WLAN 802.11(a/b/g/j/p/n/ac/af/ah/ax)
Applications-Digital Video:	n/a
Performance Level:	◆◆◆◆◆◇
Standard Attenuator Range:	70 dB
Standard Attenuator Step:	2 dB
Minimum Duration for 100% Probability of Intercept:	3.57 µs
Detectable Signal Duration w/Signal to Mask >60 dB:	3.33 ns
Spur Free Dynamic Range:	75 dBc
Multi-Domain Bandwidth:	255 MHz
Display Views:	Density Spectrogram Density Spectrogram PvT (Power vs. Time) Spectrum PvT (Power vs Time)
Triggering:	FMT (Frequency Mask Trigger) TQT (Time Qualified Trigger) Level RF Burst Line External Periodic Density Spectrogram Density Spectrogram PvT (Power vs Time) PvT (Power vs Time) Spectrogram
Applications with Frequency Mask Trigger:	89600 VSA Software Real-Time Spectrum Analyzer Pulse Measurement Application
DANL @2 GHz, No Preamplifier:	-155 dBm/Hz
DANL @10 GHz, No Preamplifier:	-157 dBm/Hz
Applications Available:	Yes
Benchtop:	Yes
Real-Time Data Streaming:	Yes
