Tektronix RSA6114B Spectrum Analyzer | 9 kHz - 14 GHz

The Tektronix RSA6114B is a 9 kHz to 14 GHz spectrum analyzer that combines high-performance spectrum analysis, wideband vector signal analysis and real-time spectrum analysis capabilities in a single test system. The Tektronix RSA6114B offers users a dynamic range ideal for difficult spectrum analysis measurements, operating at a typical 20 dBm TOI and -151 dBm/Hz DANL at 2 GHz. With the RSA6114B, users can perform a 1 GHz sweep in 10 kHz RBW in less than 1 second. The interface is fully preselected and image-free, allowing for maximum dynamic range at any acquisition bandwidth.

The Tektronix RSA6114B is part of the Tektronix RSA6000 Series.

Product Info Related Products

Frequency range	9 kHz to 14 GHz
Real-time acquisition bandwidth	40 MHz (110 MHz, opt. 110)
Trigger modes	Free run, triggered, FastFrame
Trigger types	Power (Std.), Frequency mask (Opt. 52), Frequency edge, DPX density, Runt, Time qualified
Acquisition memory	1 GB (4 GB, Opt. 53)

20 dBm 3rd order intercept at 2 GHz, typical
Displayed average noise level –151 dBm/Hz at 2 GHz (–167 dBm/Hz, preamp on, typical) enables low-level signal search
Revolutionary DPX displays transients with a minimum event duration of 3.7 μs
Trigger on frequency edge or power level transients with a minimum event duration of 3.7 μs in the frequency domain, 9.1 ns in time domain
Up to 7.15 s acquisitions at 110 MHz bandwidth can be directly stored as MATLAB compatible files

SKU: TEKT-RSA6114B-PKG01
