Keysight N9952A FieldFox Handheld Microwave Analyzer | 50 GHz

Categories

Spectrum Analyzers

Documents

Datasheet

The Keysight N9952A FieldFox Handheld Microwave Analyzer measures and analyzes data while also withstanding the toughest working environments. The device is rugged enough to meet MIL-specs. The N9952A is general-purpose and application-specific with a frequency range of 50 GHz. The Keysight FieldFox N9952A assists technicians in locating several RF measurements and is offered a variety of choices for a variety of applications. This N9952A is 5G ready due to its wide bandwidth and high-frequency range. The Keysight N9952A is dependable, effective, and long-lasting with an average battery life of 3.5 hours for longer testing and measurement times.

The Keysight N9952A unit can be activated for vector network analysis (VNA) and spectrum analysis for additional testing, making it best suited for cable and antenna testing. A power meter, independent signal generator, vector voltmeter interference analyzer, and changeable DC source are among the FieldFox N9952A optional features. The Keysight N9952A can simultaneously measure DTF and TDR. The Keysight N9952A FieldFox Microwave Analyzer is user-friendly for technicians in the field and performs everything from regular maintenance to extensive troubleshooting. The Keysight N9952A's integrated GPS receiver provides measurements with geo-location tags in addition to geo data like time, latitude, longitude, and elevation. The device can also be displayed and recorded in data files. The GPS not only offers position data but also an external reference to increase Keysight N9952A FieldFox frequency accuracy.

Specifications
Features
Applications
Options
Accessories
Standards
Videos

Maximum frequency	50 GHz
CAT/VNA start frequency	300 kHz
SA start frequency	5 kHz
Dynamic range	110 dB
Output power	4 dBm
Trace noise	0.004 dBrms
Number of Built-In Ports	2 ports
Best Speed at 1001 Point, 1 Sweep	478 us/pt
Instrument type	Combination Analyzer
Weight	7.1 lb. (3.2 kg)
Dimensions (W x H x D)	188 mm x 292 mm x 72 mm

N9952A-010	Vector Network Analyzer Time Domain
N9952A-030	Remote Control Capability
N9952A-208	USB Power Sensor Measurements Versus Frequency
N9952A-209	Extended Range Transmission Analysis (ERTA)
N9952A-210	Vector Network Analyzer Transmission/Reflection
N9952A-211	Vector Network Analyzer Full 2-port S-parameters
N9952A-212	Mixed-Mode S-parameters
N9952A-215	TDR Cable Measurements
N9952A-233	Spectrum Analyzer
N9952A-235	Pre-amplifier
N9952A-236	Interference Analyzer and Spectrogram
N9952A-238	Spectrum Analyzer Time Gating
N9952A-302	External USB Power Sensor Support
N9952A-307	GPS Receiver
N9952A-308	Vector Voltmeter
N9952A-309	DC Bias Variable Voltage Source
N9952A-310	Built-in Power Meter
N9952A-312	Channel Scanner
N9952A-330	Pulse Measurements
N9952A-350	Real-time Spectrum Analyzer (RTSA)
N9952A-351	I/Q Analyzer (IQA)
N9952A-355	Analog Demodulation
N9952A-356	Noise Figure (NF)
N9952A-360	Phased Array Antenna Control
N9952A-370	Over-the-Air (OTA) LTE FDD
N9952A-377	Over-the-Air (OTA) 5GTF
