Anritsu MS2720T Handheld Spectrum Master

9 kHz - 43 GHz

The Anritsu Spectrum Master MS2720T Handheld Spectrum Analyzer is a spectrum analysis device featuring tracking generators up to 20 GHz, a dynamic range of over 106 dB and preamplifiers with a frequency range from 9 kHz to 43 GHz. This Spectrum Master test instruments possess the functionality of over 30 analyzers to meet a wide array of measurement needs, including the abilities of a power meter, interference analyzer, channel scanner, GPS receiver, signal analyzer, PIM analyzer and more.

Product Info Available Add-Ons Related Products

Frequency range	9 kHz - 43 GHz
Dynamic range	>106 dB
Output power	30 MHz wide Zero-Span
Number of Built-In Ports	2 ports
Weight	3.7 kg to 4.4 kg (8.1 lb to 9.8 lb)
Dimensions (W x H x D)	273 mm x 199 mm x 91 mm (10.7 in x 7.8 in x 3.6 in)

Frequency Ranges: 9 kHz to 9 GHz, 13 GHz, 20 GHz, 32 GHz and 43 GHz
Internal atomic clock option for increased frequency accuracy
Measurements: occupied bandwidth, channel power, ACPR, C/I, emission mask, field strength
3G and 4G measurement options for LTE, CDMA, W-CDMA, WiMAX, GSM, and TD-SCDMA
Interference Analyzer: spectrogram, signal strength, RSSI, mapping
Dynamic Range: > 106 dB in 1 Hz RBW @ 2.4 GHz
DANL: –160 dBm in 1 Hz RBW @ 1 GHz preamp On
Phase Noise: –104 dBc/Hz @ 10 kHz offset at 1 GHz
1 Hz to 10 MHz resolution bandwidth (RBW)
Tracking generator up to 20 GHz
