Rohde & Schwarz FSWP Phase Noise Analyzer & VCO Tester
- 1 MHz - 50 GHz frequency range
- Phase noise & spectrum analysis
- High sensitivity
Tektronix RSA6114B Spectrum Analyzer | 9 kHz - 14 GHz
- 20 dBm 3rd order intercept at 2 GHz, typical
- Displayed average noise level –151 dBm/Hz at 2 GHz (–167 dBm/Hz, preamp on, typical) enables low-level signal search
- Revolutionary DPX displays transients with a minimum event duration of 3.7 μs
Tektronix RSA5126A Real-Time Spectrum Analyzer
- Frequency Range 1 Hz to 26.5 GHz.
- Trigger Modes: Free Run, Triggered, FastFrame.
- Level Range 0 dB to –100 dB from reference level.
Rohde & Schwarz FSP38 Spectrum Analyzer | 9 kHz - 40 GHz
- 15 minutes warm-up time at ambient temperature
- specified environmental conditions met, calibration cycle and total calibration
- Data without tolerances: typical values only
Anritsu MS2726C Handheld Spectrum Analyzer
- Measure occupied bandwidth, channel power, ACPR, and C/I
- Dynamic Range of >104 dB in 1 Hz RBW
- Phase Noise of –100 dBc/Hz @ 10 kHz offset at 1 GHz
Keysight N9952A FieldFox Handheld Microwave Analyzer | 50 GHz
- 50 GHz max frequency
- Carry industry’s first 50 GHz handheld µW analyzer: standard model includes cable and antenna analyzer
- Expand capabilities with optional VNA, spectrum analyzer, built-in power meter, vector voltmeter, and more
Keysight N9951A FieldFox Handheld Microwave Analyzer
- Frequency Range: 300 kHz – 44 GHz
- Dynamic Range: Up to 110 dB
- 2 Ports
Tektronix RSA518A Real-Time Spectrum Analyzer
- 9 kHz to18.0 GHz frequency range covers a broad range of analysis needs
- 40 MHz acquisition bandwidth enables real time analysis for transient capture and vector analysis
- High speed full-span sweeps (70 GHz/sec) for fast setup and discovery
Narda SignalShark 3310 Real-Time Handheld Spectrum Analyzer
- Frequency range: 8 kHz - 8 GHz
- Scan rate: > 50 GHz
- Real-time instantaneous bandwidth: 40 MHz
Rohde & Schwarz FSH18 10 MHz - 18 GHz Spectrum Analyzer
- Frequency range of 10 MHz to 18 GHz
- Reference Level -80dBm to +20dBm
- TOI typ. 7 dBm
Rohde & Schwarz FSH8 Spectrum Analyzer 9 kHz - 8 GHz
- Frequency range from 9 kHz to 20 GHz
- High sensitivity (< –141 dBm (1 Hz), with preamplifier < –161 dBm (1 Hz))
- 20 MHz demodulation bandwidth for analyzing LTE signals
Anritsu MS2713E Handheld Spectrum Analyzer
- Spectrum Analyzer: 9 kHz – 6 GHz
- Interference Analyzer with Interference Mapping
- High Accuracy Power Meter, 2-port Transmission Measurements
Tektronix RSA306B USB Real-Time Spectrum Analyzer | 9 kHz - 6.2 GHz
- Full-featured spectrum analysis capability with included Tektronix SignalVu-PC™ software
- 17 spectrum and signal analysis measurements standard
- Options for mapping, modulation analysis, WLAN, LTE, and Bluetooth standards support, pulse measurements, playback of recorded files, Signal Survey, and frequency/phase settling
Tektronix RSA306 USB Real Time Spectrum Analyzer
- 9 kHz to 6.2 GHz frequency range
- ACER Laptop with pre-installed SignalVU-PC software included
- +20 dBm to -160 dBm measurement range
Tektronix RSA6000 Series Spectrum Analyzers
- High-performance spectrum analysis Fully preselected and image free at all times for maximum dynamic range at any acquisition bandwidth Fastest high-resolution sweep speed: 1 GHz sweep
- Fully preselected and image free at all times for maximum dynamic range at any acquisition bandwidth
- Fastest high-resolution sweep speed: 1 GHz sweep in 10 kHz RBW in less than 1 second
Rohde & Schwarz ETL TV Analyzer
- Frequency range from 500 kHz to 3 GHz
- TV, FM (radio), video, audio, MPEG-2 transport stream and spectrum analysis in a single box
- FPGA and chip-based realtime demodulators for analog
Keysight E7402A EMC Spectrum Analyzer | 30 Hz – 3.0 GHz
- 9 kHz to 3.0 GHz (30 Hz to 9 kHz with UKB option)
- Automatic EMI measurements
- Log sweep
Keysight E7405A Spectrum Analyzer
- 1 Hz - 5 MHz
- +12.5 dBm TOI
- Measurement rate: ≥40/sec
Keysight E4446A PSA Series Spectrum Analyzer | 3 Hz - 44 GHz
- Optional 40 or 80 MHz analysis bandwidth to capture and measure complex signals
- -78 dB (nominal) third order intermodulation for 40 or 80 MHz analysis bandwidth
- Up to 300 MHz analysis bandwidth for calibrated VSA measurements
Keysight E4443A PSA Spectrum Analyzer, 3 Hz - 6.7 GHz
- Performance +/-0.19 dB absolute amplitude accuracy -155 dBm (-168 dBm w/preamp) displayed average noise level (DANL) -118 dBc/Hz phase noise at 10 kHz offset 81 dB W-CDMA ACLR
- +/-0.19 dB absolute amplitude accuracy
- -155 dBm (-168 dBm w/preamp) displayed average noise level (DANL)
Keysight E4408B 9 kHz - 26.5 GHz, ESA-L Standard Spectrum Analyzer
- 1.1 dB overall amplitude accuracy
- 100 Hz to 5 MHz RBW, 100 Hz to 300 Hz optional
- +7.5 dBm TOI
Keysight E4407B Spectrum Analyzer | 9k-26.5GHz
- Noise figure measurement personality
- Remotely view and control the ESA over the Internet
- 8590-series programming code compatibility
Keysight E4404B ESA-E Spectrum Analyzer
- Large high-resolution, high-contrast color display
- Flexible hardware/software environment
- Built-in floppy disk
Keysight E4403B ESA-L Basic Analyzer, 9kHz - 3.0GHz
- 1.1 dB overall amplitude accuracy
- 100 Hz to 5 MHz RBW, 100 Hz to 300 Hz optional
- +7.5 dBm TOI
Keysight E4402B Spectrum Analyzer
- 0.4 dB overall amplitude accuracy
- 1 Hz - 5 MHz Resolution Bandwidth (RBW)
- +16 dBm third order intercept (TOI)
