| Environment |
| Application field |
The instrument is intended for use in high-voltage substations and industrial environments. |
| Measurement category |
CAT I, transient voltage 1500 V |
| Temperature, operating |
0°C to +50°C (32°F to +122°F) |
| Temperature storage & transp. |
-20°C to +70°C (-4°F to +158°F) |
| Vibration |
IEC 60068-2 - 6 |
| Shock (non-operating) |
IEC 60068-2-27 |
| Humidity |
5% – 95% RH, non-condensing |
| Altitude (operational) |
<3000 m |
| Pollution degree |
2 |
| CE Marking |
| EMC |
2004/108/EC |
| LVD |
2006/95/EC |
| General |
| Mains voltage |
100 – 230 V AC, 50-60 Hz |
| Current consumption |
1 A (max) |
| Fuses, F1 / F2 |
F 2A |
| Portable version dimensions |
446 x 290 x 180 mm
(17.6" x 11.4" x 7.1") |
| Rack mounting version dimensions |
19" |
| Weight |
8.5 kg (18.7 lbs) 18.8 kg (41.4 lbs) with accessories and transport case |
| User interface |
6" LCD touchscreen |
