Cubert Ultris X20 Hyperspectral Video Camera
350nm – 1000nm
The Cubert ULTRIS X20 captures hyperspectral video data at up to 8 Hz using 164 spectral bands across a 350–1000 nm range. It delivers a 410 × 410 spatial resolution with 4 nm spectral sampling and a 12-bit global shutter sensor. The system operates without scanning using light field technology and supports integration times from 0.1 to 1000 ms. Data is processed in real time via Cubert’s CUVIS software, with support for C, C++, and Python SDKs.
| Spectral Range | 350 nm – 1000 nm |
| Spectral Bands | 164 |
| Spectral Sampling | 4 nm |
| Spatial Resolution | 410 × 410 pixels |
| Frame Rate | Up to 8 Hz (full hyperspectral cube) |
| Sensor | CMOSIS CMV20000 |
| Shutter Type | Global shutter |
| Data Depth | 12-bit |
| Field of View | 35° |
| Integration Time | 0.1 – 1000 ms |
| Data Link | Gigabit Ethernet (GigE) |
| Processed File Size | < 55 MB |
| Dimensions (W × H × D) | 60 × 60 × 57 mm |
| Weight | 350 g |
| Optional Housing | IP66 (industrial), IP68 (underwater) |
| Software | Cubert CUVIS, SDKs for C/C++/Python |
- Produces rich, 3D data cubes in real-time with no need for scanning or image combination after fast filter shifts
- Ranging from ultraviolet to near-infrared, and covering a wide range of possible applications
- Cubert Cuvis software processes raw data, reflectance, and even radiance, and allows hyperspectral videos at up to 8 Hz.
- Aerial mapping
- Food quality
- Biomedical Imaging
- Scientific research
SKU: CUBE-ULTRIS-X20
