| Platform Type | Modular protection testing system |
| Chassis Capacity | 7 module slots |
| Supported Testing | Differential, distance, transformer, transmission, and generation protection |
| Module Types Supported | High-VA Voltage, High-VA Current, Low-Density Logic I/O |
| Maximum Voltage Capability | Up to 300 V L-N (configuration-dependent) |
| Maximum Current Capability | Up to 50 A continuous; up to 90 A transient (configuration-dependent) |
| IEC 61850 Support | Sampled Values (IEC 61869-9, IEC 61850-9-2LE) and GOOSE |
| Time Synchronization | IRIG-B, IEEE 1588 / IEC 61850-9-3 PTP, SNTP, GPS 1 PPS |
| Integrated Battery Simulator | 6–300 V, 90 W |
| Software Compatibility | Protection Suite, Doble RTS, 61850 TesT, Doble PowerBase |
SKU: DOBL-F8300
