GAUSS INSTRUMENTS TDEMI eXtreme Series | 9 kHz – 1/3/6/18/26.5/40 GHz
- Real Time Spectrogram Real-time bandwith of 162.5 MHz, 645 MHz Upgrade Option Peak, Average and RMS Detector
- Real-time bandwith of 162.5 MHz, 645 MHz Upgrade Option
- Peak, Average and RMS Detector
Rohde & Schwarz ESCI7 9 kHz - 7 GHz EMI Test Receiver
- Combination of standard-compliant EMI test receiver and high-quality spectrum analyzer
- Integrated preselection with selectable 20 dB preamplifier
- Effective analysis of the disturbance spectrum through simultaneous graphical presentation of the disturbance level and emission spectrum around the receive frequency (“mixed-mode”)
PMM 9010 | 10 Hz – 30 MHz
- The marker is a very powerful feature, providing an easy-to-read frequency/amplitude value through a simple knob rotation in the window span
- Pre-loaded limits for sweep mode are stored in a nonvolatile memory, providing for CISPR Compliance
- Simultaneous detectors, QP-PK-AVGRMS, for time-coherent measurements, provide parallel indications at every frequency value in the range
Rohde & Schwarz ESL6 | 9 kHz – 6 GHz
- Frequency range from 9 kHz to 6 GHz covering almost all commercial EMC standards
- First-ever combination of an EMI test receiver and spectrum analyzer in the entry-level class
- All major functions of an advanced EMI test receiver, including fully automated test sequences
PMM 9010F | 10 Hz – 30 MHz
- The frequency range of the base PMM-9010F system can be extended to 18Ghz with the addition of the PMM 9030, 9060 and 9180 modules described in more detail below
- Frequency range: 10 Hz – 30 MHz, expandable to 3/6/18 GHz by the external modules 9030, 9060, 9180
- Very low noise floor: < -24 dBµV in band A, < -7 dBµV in band B
Rohde & Schwarz ESW Series | 1 Hz – 8/26.5/44 GHz
- Frequency ranges from 1 Hz to 8 GHz, 1 Hz to 26.5 GHz, and 1 Hz to 44 GHz
- In line with CISPR16-1-1, ANSIC63.2, MIL‑STD‑461 and FCC
- Extremely high dynamic range and ultra high accuracy for demanding certification measurements
Rohde & Schwarz ESRP | 10 Hz – 7 GHz
- Disturbance measurements in line with commercial standards Precompliance measurements EMI measurements in spectrum analyzer mode
- Precompliance measurements
- EMI measurements in spectrum analyzer mode
Narda PMM CDD-4 Continuous and Discontinuous Disturbances Analysis and Verification Set
- PMM CA0010 Click Analyzer Features Internal 16 A single-phase LISN, fully CISPR 16-1-2 compliant 150 kHz – 30 MHz: just plug the EUT power cord and go RF in front-end with preselection
- Internal 16 A single-phase LISN, fully CISPR 16-1-2 compliant 150 kHz – 30 MHz: just plug the EUT power cord and go
- RF in front-end with preselection filters and individual auto-attenuators for each of the four frequencies, to guarantee the best dynamic range as required by the challenging discontinuous
Rohde & Schwarz ESU40 | 20 Hz – 40 GHz
- Automatic and interactive measurement functions
- Parallel IF analysis
- Up to three detectors Average detector with meter time constant (CISPR-Average) RMS-Average detector APD (amplitude probability distribution to CISPR 16)
PMM CA0010 Click Analyzer | 150 kHz, 500 kHz, 1.4 MHz, 30 MHz
- Performs discontinuous disturbance (click) analysis
- Designed to fulfill CISPR 16-1-1, CISPR 14-1 and IEC/EN55014-1 test standards
- Four independent frequency channels measure simultaneously
Keysight N9038A-508 | 20 Hz – 8 GHz
- DC Coupled Frequency Range 20 Hz to 8.4 GHz
- AC Coupled Frequency Range 10 MHz to 8.4 GHz
- CISPR bandwidth 200 Hz, 9 kHz, 120 kHz, and 1 MHz; MIL-STD and bandwidths incremented in 10% steps
PMM FR4003 | 9 kHz – 30 MHz
- Antenna CISPR 12, CISPR 16, CISPR 25, MIL-STD, DO-160 fully compliant
- Internal full CISPR 16-1-1 receiver
- Embedded attenuator, preamplifier and preselectors
PMM 9180 | 6 – 18 GHz
- 6 GHz to 18 GHz Frequency Range
- 100 HZ Resolution
- < 2 ppm Reference Frequency
PMM 9030 | 30MHz – 3GHz
- Modular approach for all budgets
- Eliminates long coax cables
- Built-in automatic test routines
Rohde & Schwarz ESRP7 EMI Test Receiver | 10 Hz – 7 GHz
- EMI test receiver and signal/spectrum analyzer combined in one box
- Optional preselection and preamplifier (R&S ESRP-B2)
- Resolution bandwidths in line with CISPR, optionally in decade steps from 10 Hz to 1 MHz (R&S ESRP-B29)
Rohde & Schwarz ESW44 | 1 Hz – 44 GHz
- Standard-compliant EMI measurements in spectrum analyzer mode
- RF performance that meets exacting demands
- Exceptionally wide dynamic range
GAUSS INSTRUMENTS TDEMI ULTRA40 | 9 kHz – 40 GHz
- A frequency range from DC up to 40 GHz
- 685 MHz real-time analysis bandwidth
- Dynamic range of more than 100 dB
Rohde & Schwarz ESCI | 9 kHz – 3 GHz
- Combination of standard-compliant EMI test receiver and high-quality spectrum analyzer
- Integrated preselection with selectable 20 dB preamplifier
- Effective analysis of the disturbance spectrum through simultaneous graphical presentation of the disturbance level and emission spectrum around the receive frequency (“mixed-mode”)
Rohde & Schwarz ESR | 10 Hz – 26.5 GHz
- Compliant with CISPR 16-1-1 Ed. 3.1
- Preselection with integrated 20 dB preamplifier
- Resolution bandwidths in line with CISPR and optionally in decade steps from 10 Hz to 1 MHz (MIL STD-461, DO-160)
PMM ER9000 | 10 Hz – 3 GHz
- ER9000 Opt. 01: 10 Hz - 3 GHz
- Very fast FFT scan gapless (2 sec. In Band B, 1 min. In Band C + D)
- Color Touchscreen display
Keysight N9038A MXE Series | 3 Hz – 3.6/8.4/26.5/44 GHz
- Consistent measurement framework
- Broadest set of applications
- Upgradeable processor, memory, connectivity, and more
PMM PL-01 9 kHz – 30 MHz Pulse Limiter
- Designed according to criteria of cheaply and compactness, it can be used together with PMM 8010 System for Conducted Interferences measurement, or any other RF receiver.
GAUSS INSTRUMENTS TDEMI X40 | 9 kHz – 40 GHz
- Frequency range from DC up to 40 GHz
- 645 MHz real-time analysis bandwidth
- Dynamic range of more than 100 dB
PMM ER8000 FFT | 9 kHz – 3 GHz
- Full compliant Measurement band B in 2 seconds
- Full compliant Measurementb band C+D in 60 seconds
- Built-in 16 A single phase LISN
Keysight N9038A-526 | 3 Hz – 26.5 GHz
- DC frequency range 20 Hz to 26.5 GHz
- AC frequency range 10 MHz to 26.5 GHz
- CISPR bandwidth 200 Hz, 9 kHz, 120 kHz, and 1 MHz (MIL-STD and bandwidths incremented in 10% steps)
