Fluke 5450A Resistance Calibrator 1.0 Ω - 100 MΩ

Resistance Calibrator 1.0 Ω - 100 MΩ

The Fluke 5450A Resistance Calibrator provides precision resistance outputs from 10 ohms to 100 megohms for calibrating digital multimeters. It supports four wire measurement configurations with defined accuracy and stability across multiple ranges. The instrument includes front panel control and an IEEE 488 interface for automated operation. It displays the selected resistance value and measurement error in percent or parts per million for the unit under test.

Product Info Related Products

Resistance Output Range	10 Ω - 100 MΩ selectable at decade points and ×1.9 values
Resistance Selection Resolution	Decade values 10 - 1000 multiples and ×1.9 series values
Four-Wire Absolute Uncertainty	±7.5 ppm - ±200 ppm depending on value range and time interval
Stability	±2 ppm - ±195 ppm depending on resistance value and calibration interval
Maximum Output Current	0.5 µA - 500 mA depending on resistance value
Maximum Output Voltage	0.25 V - 50 V depending on resistance value
Temperature Coefficient	±1.5 ppm/°C - ±10 ppm/°C over 0 °C - 50 °C
Two-Wire Compensation	12 mΩ - 1000 mΩ additional error depending on resistance and conditions
Measurement Configuration	Four-wire Kelvin connection and two-wire with compensation
Interface	IEEE‑488-1978 compliant interface with SH1 AH1 T8 L4 subsets
Warm-Up Time	2 hours at 18 °C - 28 °C and 4 hours at 0 °C - 40 °C
Power Requirements	100 V - 240 V AC ±10% at 50 Hz - 60 Hz <50 W
Operating Environment	0 °C - 40 °C up to 80% RH and storage −40 °C - 75 °C up to 95% RH
Physical Characteristics	8.89 cm × 55.37 cm × 43.18 cm and 9.3 kg weight
