Magna Power XR600-13.3 DC Power Supply
0 - 600 Vdc, 0 - 13.3 Adc
Magna-Power XR600-13.3s are 600V, 13.3A DC power supplies that offer up to 8kW of power. These power supplies satisfy the increasing demand for a variety of applications, such as ATE, power source and solar emulation, water treatment, and many other research and development activities. They can accept a wider AC input voltage range than any comparable product: from 208 - 480VAC, at 50Hz, 60Hz, and 400Hz all with efficiencies up to 88%.
| Voltage: | 0 - 600Vdc |
| Current: | 0 - 13.3Adc |
| Ripple: | 280mVrms |
| Efficiency: | 88% |
| Input current: | 208/240V: 28.0Aac |
| 380/415V: 17.0Aac | |
| 440/480V: 15.0Aac |
- High power density
- Wide voltage and current range
- High efficiency operation
- 37-pin optically isolated user I/O circuitry standard front panel analog potentiometers: Stepless rotary control
- RS-232 interface standard with SCPI Commands:
- GPIB, USB, Ethernet, RS-485 interfaces optional
- Optional LXI-certified Ethernet communications: Embedded web-server
- OVT and OCT shutdown standard: Mechanical contactors to disconnect input mains
- Certified LabWindows/CVI and LabView Drivers: GPIB, Serial, and TCP/IP
- Programmable Output Modulation: Emulates user-defined power profiles
- High power factor
SKU: MAGN-XR600-13.3/208
