Teseq PNW 2051 Impulse Network for NSG 2050
Tech Support
(800) 404-2832
With Every
Rental
Worldwide
Delivery
Larger
Categories
Transient Generators
Documents
Manual
Specifications
Print
Email
This product has been discontinued.
View the Transient Generators
Impulse Networks for NSG 2050
Specifications
Features
Applications
Options
Accessories
Standards
Videos
Features
Specifications
Pulse Form:
0.5/700 µs (open-circuit)
10/700 µs (short-circuit)
Voltage: 200 V to 6600 V adjustable in 10 V steps
Short-Circuit Current:
13.3A to 440 A ±10% into 15 ohms impedance
5 A to 165 A ±10% into 40 ohms impedance
Impedance: 15 ohms, 40 ohms
Polarity: P (positive), N (negative), A (alternating)
Pulse Outputs: Earth-free (floating)
Repetition: 15 s to 10000 s
Number of pulses: 1 to 9999
Applications
Options
Accessories
Optional Accessories: CDN 118
Standards
IEC 1000-4-5 (IEC801-5)
CCITT
NF C98-010
Telecordia GR-1089
Media
RELATED PRODUCTS
Haefely PSURGE 30.2 Surge Test System | 30 kV / 30 kA
Haefely AXOS5 Compact Immunity Test System
Teseq NSG 3060 Transient Generator
Haefely AXOS 8 Compact Conducted Immunity Test System
M Precision Laboratories EMCPro PLUS EMC Test System
Teseq CDN 3083-S100 3 Phase, 100 Amp, 690 Volt Surge CDN
Haefely PSURGE 8000 Surge Platform Test System
Teseq NSG 3040 Transient Generator
EM Test NX5 Multifunctional Test Generator
EM Test OCS 500N6F Damped Oscillatory Wave Simulator 3MHz/10MHz/30MHz
Compliance West MegaPulse D5-PF Defibrillation Proof Tester
NoiseKen INS-4040 Impulse Noise Simulator
EMC Partner IMU3000 Immunity Tester
Teseq NSG 3150 15 kV Combination Wave Surge Generator
Thermo Keytek ECAT E103 Control Center
Teseq NSG 3025 Burst Generator
EMC Partner DOW3000 Oscillatory Wave Generator
EM Test UCS 500N5 Multifunctional EFT, Surge & Power Fail Generator
Teseq NSG 3040-SOW Slow Oscillating Waveform Generator
Thermo Keytek ECAT Computer-Aided EMI Immunity Test System
EM Test NX7 Multifunctional Test Generator
Haefely MAG 1000 Power Frequency Magnetic Field Test Equipment
Teseq INA 702 Magnetic Field Coil
Haefely PLINE 1610 Voltage / Interruption Tester for IEC 61000-4-11
Haefely PEFT Junior Burst Tester
With Every
