AH Systems PAM-1840VH Preamplifier 18 GHz - 40 GHz

Rent AH Systems PAM-1840VH Preamplifier 18 GHz - 40 GHz
Enlarge Image
Request Quote Print Page

The AH Systems PAM-1840VH Preamplifier 18 GHz - 40 GHz is an excellent choice with a rugged design, no hassles with soldering your own power leads and they improve overall system sensitivity by at least 25 dB. All of A.H. Systems' Preamplifiers come with a 15-volt DC regulated power source. A low voltage indicator confidently allows you to power the amplifier with your own external 15-volt DC battery. This makes it a convenient choice for field measurements. See table above for amplifier specifications.


Features:


  • Frequency Range of 18 GHz to 40 GHz
  • High Gain
  • Individually Calibrated (gain calibration included)
  • Low VSWR



Specifications:



Frequency Range: 18 GHz - 40 GHz
Gain (typical): 37 dB
Gain (minimum): 33 dB
Noise Figure: 3.7 dB
Flatness: +/- 3.5 dB
Maximum Power (dBM) @ 1 dB: +8 dBm
VSWR (typical): less than 2.9:1
Input Power: 100/220 VAC regulated P/S
output: 15 VDC  275 mA
