The Flexim Fluxus F601 Portable Flowmeter is the portable clamp-on flow meter of choice for servicing and maintenance activities, the control and auditing of measurement points not covered by permanent meters, or even the temporary replacement of permanently installed flow meters. The Flexim Fluxus F601 is measurement ready in less than 5 minutes, including the measurement of the pipe wall thickness, the connection of the transducers to the transmitter, the parameterization of the flow meter and finally the mounting of the transducers.

The Flexim Fluxus F601 was designed to easily withstand rough industrial environments while featuring an ergonomic design, which offers simple handling and maximum ease of use. Besides its sturdy housing, the Flexim Fluxus F601 features stable and precise latching transducer connectors and stainless steel armored cables to prevent damage during daily work. With its Li-Ion battery, the F601 allows for up to 14 hours of autonomous measurement. Matched and paired transducers as well as sophisticated algorithms correct for pipe wall echoes and wrong transducer positioning, thus ensuring reliable and highly accurate measurements - even under the most demanding application conditions. Due to the new HybridTrek mode, the portable flow meter can also reliably and accurately measure liquid flow under conditions with a high fraction of solid particles or gaseous loads.

Specifications
Features
Applications
Options
Accessories
Standards
Videos

Features

Precise bi-directional and highly dynamic flow measurement with the non-intrusive clamp-on technology
High precision at fast and slow flow rates, high temperature and zero point stability
Portable, easy-to-use flow transmitter with 2 flow channels, multiple inputs/outputs, an integrated data logger with a serial interface
Water and dust-tight (NEMA 4); resistant against oil, many liquids and dirt
Li-Ion battery provides up to 14 hours of measurement operation
Automatic loading of calibration data and transducer detection for a fast and easy set-up (less than 5 min), providing precise and long-term stable results
User-friendly design
Transducers available for a wide range of inner pipe diameters (0.25 to 256 in) and fluid temperatures (-40 to +752 °F)
Probe for wall thickness measurement available
Robust, water-tight (NEMA 4) transport case with comprehensive accessories
HybridTrek automatically switches between transit time and NoiseTrek mode of measurement when high particulate flows are encountered
QuickFix for fast mounting of the flow transmitter in difficult conditions

Specifications

±1.2 % of reading ±0.03 ft/s

Measurement
Measurement principle	transit time difference correlation principle, automatic NoiseTrek selection for measurements with high gaseous or solid content
Flow velocity	0.03 to 82 ft/s
Repeatability	0.15 % of reading ±0.03 ft/s
Fluid	all acoustically conductive liquids with < 10 % gaseous or solid content in volume (transit time difference principle)
Temperature compensation	corresponding to the recommendations in ANSI/ASME MFC-5.1-2011
Accuracy¹
With standard calibration	±1.6 % of reading ±0.03 ft/s
with advanced calibration (optional)	±1.2 % of reading ±0.03 ft/s
with field calibration²	±0.5 % of reading ±0.03 ft/s
Flow transmitter
Power supply	100 to 230 V/50 to 60 Hz (power supply unit) 10.5 to 15 V DC (socket at transmitter) integrated battery
Integrated battery - operating time	Li-Ion, 7.2 V/6.2 Ah 14 h (without outputs, inputs andbacklight) 25 h (1 measuring channel, ambient temperature > 50 °F, without outputs, inputs andbacklight)
Power consumption	< 6 W (with outputs, inputs and backlight)
Number of flow measuring channels	2
Damping	0 to 100 s, adjustable
Measuring cycle (1 channel)	100 to 1000 Hz
Response time	1 s (1 channel), option: 70 ms
Housing material	PA, TPE, AutoTex, stainless steel
Degree of protection	NEMA 4
Dimensions	see dimensional drawing
Weight	4.6 lb
Fixation	QuickFix pipe mounting fixture
Ambient temperature	14 to 140 °F
Display	2 x 16 characters, dot matrix, backlight
Menu language	English, German, French, Dutch, Spanish
Measuring functions
Physical quantities	volumetric flow rate, mass flow rate, flow velocity, heat flow (if temperature inputs are installed)
Totalizer	volume, mass, optional: heat quantity
Calculation functions	average, difference, sum
Diagnostic functions	sound speed, signal amplitude, SNR, SCNR, standard deviation of amplitudes and transit times
