Keysight E5810A LAN/GPIB Gateway

HP/Agilent E5810A LAN/GPIB Gateway, remote access andcontrol of GPIB instruments
Enlarge Image
Keysight E5810A
Request Quote Print Page
Manual Datasheet Accessory Kit Other1

Directly connect your test-and-measurement instruments to your PC or network in several different ways. For the fastest and easiest connections, Keysight converters let you take advantage of USB and LAN - the standard I/O already available in your computer. The USB/GPIB interface offers a direct connection from the USB port on your laptop or desktop PC to GPIB instruments from any vendor. There are no switches to set or PC cards to install.


For benchtop or system applications, the LAN/GPIB gatewayprovides remote access and control of GPIB instruments via 10BASE-T or 100BASE-Tx networks; enabling resource sharing, global project communications and remote access to instruments. Or if you prefer, the High Performance GPIB card plugs into the back plane of your computer and provides high system throughput.


The Keysight connectivity solutions offer a direct connection toyour PC using standard interfaces - GPIB, USB, or LAN. The interface includes hardware and Keysight VISA/SICL IO Libraries software. The VISA software provides an industry-standard method to connect-to and control your instrumentation.


Keysight E5810A Specs
Specifications
Description

LAN/GPIB Gatewayprovides remote access andcontrol of GPIB instruments

Operating System

Windows® 98(SE)/Me/NT/2000/XP

IO Libraries VISA/SICL
Interface 10BASE-T/100BASE-Tx
