Lighthouse Worldwide Solutions LS60 Liquid Particle Counter

The Lighthouse Worldwide Solutions LS60 Liquid Particle Counter is an integrated particle counter with 8 channel sizes. With RS-485 MODBUS communication, a built-in magnetic stirrer, and more, the LS60 model provides technicians with the technology needed for efficient and precise operation. The LS60 has a size range of 0.1 µm to 100 µm and a flow rate of 60 ml/min.

Product Info Related Products

Model	LS60
Size Range	0.1 µm - 100 µm
Flow Rate	60 ml/min
Channel Sizes	0.1, 0.15, 0.2, 0.25, 0.3, 0.35, 0.4, 0.5 µm 0.2, 0.3, 0.4, 0.5, 0.7, 1.0, 1.3, 2.0 µm 0.3, 0.5, 0.7, 1.0, 1.3, 2.0, 2.5, 3.0 µm 0.5, 1.0, 2.0, 5.0, 10.0, 25.0, 50.0, 100.0 µm
Number of Channels	8
Laser Source	Laser diode
Syringe Size	25 ml
Sample Volume	User-defined (based on syringe capacity)
Communication Mode	RS-485 MODBUS
Connectors	RJ-45
Supporting Software	LS-60 Software
Compliance	ISO 21501-3
Software Compliance	21 CFR Part 11 capable
Power Requirements	24 VDC (typical, confirm with manual)
Environmental Conditions	10°C - 40°C; < 85% RH non-condensing (typical)
Dimensions (L x W x H)	12.85 x 8.75 x 14.58 in (32.64 x 22.23 x 37.03 cm)
Weight	20.5 lb. (9.3 kg)
