Keysight U7227A USB Preamplifier | 10 MHz to 4 GHz
- Automatic temperature-compensated gain corrections and calibration data transfer (noise figure and S-parameters) through USB plug-and-play improve noise figure measurements with Keysight X-Series
- Excellent noise figure and optimized gain with the X-Series signal analyzers improves measurement accuracy and minimizes uncertainty
- Broadband operating frequency from 10 MHz up to 4 GHz for various applications
Keysight N8975B Noise Figure Analyzer | 10 MHz to 26.5 GHz
- Frequency range 10 MHz to 26.5 GHz in a one-box solution
- Multi-touch interface
- Includes Spectrum Analyzer and IQ Analyzer (Basic) modes
Keysight 8970A/346B Noise Figure Meter
- Noise figure (gain) measurement range: 0 to 30 dB (-20 to at least 40 dB)
- Noise figure resolution: .01 dB (.001 dB over HP-IB)
- Gain resolution: .01 dB (.001 dB over HP-IB)
Keysight N8974B Noise Figure Analyzer | 10 MHz to 7 GHz
- Frequency Range 10 MHz to 7 GHz in a one- box solution
- Multi-Touch Interface
- Includes Spectrum Analyzer and IQ Analyzer (Basic Modes)
Keysight N8972A Noise Figure Analyzer, 10 MHz- 1.5 GHz
Keysight 346C Noise Source
- Frequency range | 10 MHz - 26.5 GHz
- Impedance | 50 Ω
- Nominal ENR | 15 dB
Keysight 8970B Noise Figure Meter, 10 MHz - 1.6 GHz
- Frequency Range: Tunable from 10 to 1600 MHz (10 to 2047 MHz with option 020)
- Tuning Accuracy (for 10 to 40°C): ±(1 MHz + 1% of frequency); 6 MHz maximum
- Frequency Resolution: 1 MHz
NoiseCom NC9663 Programmable Noise Source, 100 Hz - 200 MHz
Keysight N8973B Noise Figure Analyzer | 10 MHz to 3.6 GHz
- Frequency range 10 MHz to 3.6 GHz in a one-box solution
- Multi-touch interface
- Includes Spectrum Analyzer and IQ Analyzer (Basic) modes
Keysight N8976B Noise Figure Analyzer 10 MHz - 40 GHz
- Easy Noise Figure Measurement Setup
- Low Noise Figure Measuring Instrumentation Uncertainty
- Increase Measurement Throughput
