Haefely PSURGE 8000 Surge Platform Test System

The Haefely PSURGE 8000 Surge Platform Test System is a modular solution designed for precision surge testing across various applications. Central to the system is the PSURGE 8000 Controller, a PC-based host that manages independent impulse (PIM #X) and coupling/decoupling (PCD #X) modules. This design ensures versatility and adaptability to meet evolving testing standards and requirements. The system’s user-friendly interface, combined with its rugged construction, guarantees precise control and reliable performance. Ideal for industrial, telecom, and research applications, the PSURGE 8000 enables accurate and efficient surge testing needs.

Product Info Available Add-Ons Related Compliance Standards Related Products

Impulse Modules

PIM 100 (Combination Wave Impulse Module)	Built according to IEC/EN 61000-4-5 Ed. 1 & 2 and ANSI C62.41/45 1.2/50 µs open circuit up to 7.4 kV 8/20 µs short circuit up to 3.7 kA Impulse voltage and current monitors ± 1° phase synchronization Reliable semiconductor HV-switch Positive, negative and alternating polarity Up to 12 pulses per minute
PIM 110 (Ring Wave Impulse Module)	Built according to IEC/EN 61000-4-12 and ANSI C62.41/45 100 kHz frequency, 0.5 µs rise time Imp. voltage up to 7.8 kV / 12 Ω, 30 Ω and 200 Ω Impulse voltage and current monitors ± 1° phase synchronization Positive, negative and alternating polarity Up to 12 pulses per minute Reliable semiconductor HV-switch
PIM 120 (Telecom Wave Impulse Module)	Built according to IEC/EN 61000-4-5 Ed. 1 & 2, ITU K-series and IEC 60950 10/700 µs open circuit voltage 5/320 µs short circuit current Imp. voltage up to 7.4 kV / 15 Ω and 40 Ω Impulse voltage & current monitors Reliable semiconductor HV-switch Positive, negative and alternating polarity Up to 12 pulses per minute
PCD 120 (Four Wire Coupling Unit for Telecom Wave)	4 wire coupling unit for unshielded symmetrical operated lines Compliant with IEC 61000-4-5 (10/700 μs impulse only), ITU K.20 / K.21 / K.44 / K.45 Fully automated operation
PIM 150 (Oscillating Wave Impulse Module)	Built according to IEC/EN 61000-4-12 Ed.1, IEC 61000-4-18 Ed.1, IEC 60255-22-1 and ANSI C37.90 100 kHz and 1 MHz burst frequencies 75 ns rise time Impulse voltage up to 3.3 kV / 200 Ω Integrated, fully automatic CDN for three-phase AC and DC power lines EUT mains voltage up to 480 V / 277 V 16 A Impulse voltage monitor Capacitive coupling clamp available optionally (IP 4 A) Data line CDN available optionally (PCD 150)

Standard PIM #X modules cover the most common surge standards, such as EN, ETSI, IEC, Telcordia (Bellcore), FCC (TIA) 68, UL 1741, ITU, ANSI, IEEE, & more
Any customized Waveform can be easily realized and integrated in a new or existing PSURGE 8000 system
Various Coupling/Decoupling networks for power lines 1 Phase and 3 Phase up to 690V / 100A are available
A selection of Coupling network for data & signal lines up to 24 outputs are on-hand
Test routine Storage and Recall, up to 36 tests & programs
WinFEAT&R Windows 98/00/NT/XP Software, is a Drag & Drop control, measuring and reporting software, for your full automated test procedure and test report
