Keysight N5221B PNA Microwave Network Analyzer 10 MHz to 13.5 GHz

The Keysight N5221B PNA Microwave Network Analyzer 10 MHz to 13.5 GHz is an integrated and flexible test engine that can measure active devices such as amplifiers, mixers, and frequency converters. This analyzer operates at a frequency range of 900 Hz to 13.5 GHz. The Keysight N5221B provides a combination of excellent hardware and powerful measurement applications to measure a broad range of devices quickly and accurately.

As part of the PNA series, the Keysight N5221B can apply to many of the measurement applications developed for the PNA-X series. These applications include gain compression, intermodulation distortion, source-phase control, and differential and I/Q devices. In each of these applications the user can expect low receiver noise floor, high receiver compression level, fast measurement speed (3.6 to 23 μsec/point) and high stability.

The Keysight N5221B PNA Microwave Network Analyzer 10 MHz to 13.5 GHz is part of the Keysight PNA Series.

Product Info Related Products

Frequency Range	900 Hz-13.5 GHz
Dynamic Range	127 dB
Built-in Ports	2 or 4
Harmonics	-19 dBc

PNA Network analyzer software tools for investigating, characterizing & troubleshooting designs
Advanced Design System (ADS): complete, integrated set of fast and accurate circuit & system simulators
Configurable test set
Up to 15 markers per trace
200 measurement channels and unlimited traces
Context sensitive, built-in help
Equation editor and time-domain analysis

Real-time S-parameter and power measurement uncertainty
Gain compression
Intermodulation distortion
Noise figure using standard receivers
Source-phase control
Differential and I/Q devices
Frequency Converters

SKU: KEYS-N5221B
