The UFX7110 noise generating instrument is extremely easy to use, combining dedicated keys for control of operations and programming with a large 4 x 20 character LCD display for instant status information. The instruments are direct replacements for NoiseCom's NC7000 Series instruments.
The UFX7110 contains a NoiseCom amplified noise source that is tuned to provide the best flatness at the instrument output. The amplifier is optimized to deliver an output with a Gaussian amplitude distribution. Noise output power level can be adjusted from 0 to 127 dB in 1 dB (optionally 0.1 dB) steps.
Specifications
| Output |
White Gaussian noise |
| Attenuator |
0 to 127 dB in 1 dB steps |
| 0 to 79 dB above 2 GHz |
| (0.1 dB steps optional) |
| Control |
Local and IEEE-488 |
| Impedance |
50 Ω (others optional) |
| Typical VSWR |
1.5:1 |
| Standard Output Connector |
SMA female (K female for UFX7240) |
| Frequency Range |
100 Hz to 1.5 GHz |
| Output Power |
+10dB |
| Output dB/Hz |
- 82 |
| Output Flatness: |
±1.5 dB |
