The OMS LaserScan LS01 Scanning Laser Vibrometer offers a complete, high-quality, cost-effective solution for full-field non-contact vibration characterization, structural analysis, operation deflection shapes, and experimental modal analysis. The turnkey LaserScan LS01 Scanning Laser Vibrometer is an integrated scanning vibrometer and data acquisition system that is designed to meet the needs of a wide range of industries.

The system is suited for a variety of measurement goals, including troubleshooting, design verification, finite element model validation, and fundamental research. When you need to visualize the motion of your test object, look no further than the OMS LaserScan Scanning Laser Vibrometer LS01.

Velocity Range	5 microns/sec to 800 mm/sec
Frequency Range	0.1 Hz to 20 kHz
Working Distance	0.1 to 5 m
Beam Size	1 mm diameter
Scan Range	± 20 degrees, each axis
Low Pass Filters	1, 2, 5, 10, 20 kHz
Power Requirements	110–220 V at 50–60 Hz
