Rohde & Schwarz TSMA Autonomous Mobile Network Scanner

The Rohde & Schwarz TSMA Autonomous Mobile Network Scanner is a comprehensive communications tool to complete both walk tests and drive tests. This compact device performs a wide range of applications. The scanner has a user-configurable frequency range between 350 MHz and 4.4 GHz. The multiband Rohde & Schwarz TSMA, which features a bandwidth of 20 MHz, protects your investment and allows you to measure various standards. Whether it is because of the flexible band selection or high-performance processor platform, this product is worth the investment and the TSMA Autonomous Mobile Network Scanner assists in testing and comes with a helpful web interface.

Product Info Related Products

Base Unit Components	R&S TSME drive test scanner unit Integrated Intel PC with a high-performance i5 processor and an embedded Microsoft Windows Operating System (Windows 7, 64 bit). Internal SSD ensuring high data processing speeds and sufficient memory (128 GB ) for measurement data.
Antennas	GPS: active antenna with cable and SMA connector included in package RF antenna: 700 MHz to 2600 MHz paddle antenna included in package Bluetooth^®/WiFi antennas included in package Optionally: R&S TSME accessory antennas
Connection cables	12V DC power supply cable with a cigarette lighter connector (included in package) LAN cable to connect host PC (RJ45 Patch cable CAT6 2m, included in package) LAN cable to connect scanner unit and internal PC unit (5016.1890.00, included in package)
AC power supply	TSMA-Z1 (1523.8450.02), optional

User-definable input frequency range from 350 MHz to 4400 MHz
RF and signal processing path with a bandwidth of 20 MHz
Parallel measurement of all technologies in all bands (up to eight technologies simultaneously)
Integrated Intel PC with Microsoft® Windows operating system which allows to install any drive test software supporting the R&S TSMA (e.g R&S ROMES)
Open remote ViCom interface in order to integrate into Windows and Androidbased software tools.
Automatic detection of active channels in a specified band (Automatic Channel Detection (ViCom only), R&S TSMA-K40, Order No. 1524.6339.02 or R&S ROMES4ACD )
Analysis of the DL allocations of the strongest eNodeBs during measurement (LTE Downlink Allocation Analyzer, R&S TSMA-K31, Order No. 1524.6322.02)

SKU: ROHD-TSMA-PKG01
