Fluke 123 2-Channel Industrial ScopeMeter

Fluke 123 2-Channel Industrial ScopeMeter
Enlarge Image
Fluke 123
Request Quote Print Page
Specifications

Features:

  • NiCad battery operation and charger: 5 hrs
  • Size: 9.1" H x 4.5" W x 2.0" D
  • Approx. Weight: 2.5 lb
  • Bandwidth: 20 MHz
  • Maximum repetitive sample rate: 1.25 GS/s
  • Number of channels: 2
  • Rise time: <17.5 ns
  • Time/division: 20 ns-60 sec
  • Volts/division: 5mV-500V
  • Record length (bytes): 512
  • Screen/waveform/set-up memories: 2 / - / 10
  • Continuous AUTOSET
  • Glitch capture down to 40 ns
  • Video triggering; interlaced, NTSC, PAL, SECAM (line and field selectable)
  • Video triggering; high resolution video, non-interlaced (line selectable)
  • Pre and post trigger adjustment in divisions: -10 to +10
  • Envelope Mode (Min/Max) and
  • Waveform Smooth
  • Measure amps with optional current clamps


Autoranging True-RMS Multimeter Features:

  • Number of DMM channels: 2
  • Display readout (basic dc accuracy 0.5%): 5000 counts
  • Advanced measurements (temp., current, % duty, pulse width, dB, Hz, amps, and more)
  • Diode Test and Continuity Beeper
  • Min Max TrendPlot with time and date stamp: 2 channel
  • DMM measurements with waveform
  • Capacitance: 50 nF - 500 µF
