Voltage |
208 V / 60 Hz (Nema N5-20 Plug, R449A) |
Dimensions
(W x L x H) |
22.4 in x 29.3 in x 34.6 in
568.96 mm x 744.22 mm x 878.84 mm |
Weight |
330.7 lb. (150 kg) |
Volumes |
Internal usable expansion volume: 4. 8 L
Minimal process volume: 8 L
Active heat exchanger volume: 1.7 L |
Pump connections |
M24x1.5 male |
Working temperature range |
-75°C - +250°C (-103°F - 482°F) |
Temperature stability |
±0.01°C - ±0.05°C |
Ambient temperature |
+5°C - +40°C |
Temperature display resolution |
0.01°C |
Cooling |
2-stage Air compressor cooling
1.12 kW @ 20°C (cool)
1.8 kW (heat) |
Max. flow rate |
40 L/min |
Pump pressure |
Up to 1.7 bar (4.4 - 24.7 psi) |
Display |
Built-in 5.7’’ industrial color touchscreen |
Analog connections |
RS485
Profibus DP
Pt100 sensor connection |
