Measuring modes |
Multiple-Echo using 3 sound pulses to ignore coatings up to 20mm thick
Echo-Echo using 2 sound pulses to ignore coatings up 1mm thick
Single-Echo using 1 sound pulse |
Materials |
Sound velocities between 1000 – 9000 m/s – covers virtually all common engineering materials |
Accuracy |
±0.1 mm or 0.1% of thickness measurement, whichever is greatest, when calibrated in accordance with Cygnus Instruments calibration procedure |
Resolution |
Multiple-Echo mode – 0.1 mm or 0.05 mm
Single-Echo and Echo-Echo modes – 0.01 mm |
