System output |
Voltage: 1 - 100 kV
Current: 50 mA (100 kV tap) / 100 mA (50 kV tap) |
Current ranges (auto) |
0 - 1000 μA, 0.1 – 100 mA |
Measurement accuracy |
±1.5% of Reading ±0.2% F.S. |
Voltage resolution |
100 V |
Current resolution |
0.1 µA |
Dimensions (W x D x H) |
20 in x 14 in x20 in (50 cm x 35 cm x 51 cm) |
Weight |
Bonnet: 135 lb. (62 kg)
Controller: 35 lb. (16 kg) |
Operating temperature |
-10°C to +50°C and 5 to 95% RH |
