Keysight 8990B RF Peak Power Analyzer | 50 MHz – 40 GHz
- 160 MHz video bandwidth
- 100 MSa/ sec continuous sampling with >1500 readings/ sec
- Frequency range of 50 MHz to 40 GHz (sensor dependent)
Keysight E4417A EPM-P Series Dual-Channel Power Meter
- 9 kHz to 110 GHz
- -70 to +44 dBm
- 500 ns ± 100 ns
Keysight U2022XA
- Frequency range of 50 MHz to 40 GHz
- Wide dynamic range of -30 to +20 dBm (peak/gated), -45 dBm to 20 dBm (average only mode)
- 30 MHz video bandwidth
Keysight N1912A P-Series Dual Channel Power Meter
- 30 MHz video bandwidth
- 100 Msamples per second
- Accuracy ±10 ppm
Boonton RTP5000 Series Real-Time Peak Power Sensors
- RTP5518: Frequency Range | 50 MHz - 18 GHz
- RTP5540: Frequency Range | 50 MHz - 40 GHz
- RTP5518/RTP5540: Dynamic Range: Pulse | -40 … +20 dBm
Keysight N1914A EPM Series Dual-Channel Power Meter | 9 kHz - 110 GHz
- Frequency range of 9 kHz to 110 GHz (sensor dependent)
- Wide dynamic range of -70 to +44 dBm (sensor dependent)
- Speed improvement by 2X for E-Series sensors: up to 400 readings/sec
Keysight E4412A E-Series Wide Dynamic Range Power Sensor
- Fast measurement speed, up to 400 readings per second with the E4416A
- Wide dynamic range (-70 dBm to +20 dBm)
- Calibration factors, linearity ana temperature compensations data stored in EEPROM
Keysight E9300 Power Sensor | 10 MHz to 18 GHz
- Frequency range of 10 MHz to 18 GHz
- Dynamic range of -60 to +20 dBm
- Operation with E4418A/B, E4419A/B, E4416A and E4417A power meters
Keysight U2002A-H26 USB Power Sensor
- Frequency range of 50 MHz to 24 GHz
- Extended frequency of 10 MHz to 26.5 GHz with option H26.
- Wide dynamic range of -60 to +20 dBm
Keysight N1924A Wideband Power Sensor, 50 MHz to 40 GHz
- Zero and calibrate while connected to the DUT
- -35 dBm to +20 dBm wide dynamic range for peak power measurements
- Calibration factors, linearity, temperature and bandwidth correction data stored in EEPROM
Keysight E9327A Peak and Average Power Sensor
- 5 MHz video bandwidth, ideal for E-CDMA and cdma2000 applications
- Fast measurement speed, up to 1000 corrected readings per second, via the GPIB
- Wide dynamic range
Keysight N1922A P-Series Wideband Power Sensor
- Frequency Range: 50MHz - 40GHz
- Dynamic Range: –35... 20dBm (≥500MHz)
- Dynamic Range: –30... 20dBm (50 - 500MHz)
Keysight E4419B EPM Dual-Channel Power Meter
- Frequency Range: 9kHz to 110GHz, sensor dependent
- Power Range: -70dBm to +44dBm (100pW to 25W), sensor dependent
- Power Sensors: Compatible with all 8480 series and HP E series sensors
Keysight U8488A-100 USB Thermocouple Power Sensor
- Frequency range of 10 MHz to 67 GHz
- Fastest measurement speed for thermocouple sensor, > 900 readings/s (free run/fast buffer mode)
- Best-in-class power linearity of less than 0.8%
Keysight N1921A P-Series | Wideband | 50 MHz – 18 GHz
- Zero and calibrate while connected to the DUT
- -35 dBm to +20 dBm wide dynamic range for peak power measurements
- Calibration factors, linearity, temperature and bandwidth correction data stored in EEPROM
Werlatone WPM11101 RF IN-Line Power Meter
- Local and/or remote monitoring
- Forward power reading/monitoring (watts or dbm)
- Reverse power reading/monitoring (watts or dbm)
Keysight 8481B RF Power Sensor
Keysight 8481D Diode Power Sensor 10 MHz to 18 GHz
- Accurate average power measurements over -70 to -20dBm
- Compatible with EPM, EPM-P and P-series power meters, plus the E1416A
- Diode power sensing element
Bird 4421 Multifunction Power Meter
- ±1% Accuracy - Accomplished through the use of sensors with an automatic frequency compensation scheme, where the error contributions due to directional coupler frequency response
- Wide Dynamic Range - The instrument will meet the full accuracy specification over a 35 dB dynamic range
- Excellent Measurement Repeatability - Typically <0.1%
Bird 4022 Directional Power Sensor
- Cost-effective solution for maintaining critical RF systems
- Only 4 models are required to cover the frequency range of 1.8 MHz to 1 GHz and power range from 300 mW - 10 kW
- Full-Scale Accuracy ±3% for applications requiring accurate forward and reflected power measurement
Keysight 8482A Power Sensor
Rohde & Schwarz NRT2 RF Power Meter
- Frequency: 25MHz - 1GHz (NRT-Z14)
- Frequency: 0.2 - 4GHz (NRT-Z44)
- Analog bargraph and autoscale
Rohde & Schwarz NRP2 RF Power Meter
- Level range: -67dBm... 45dBm
- Frequency range: DC - 110GHz
- Measurement speed: 1500 measurements/sec
Rohde & Schwarz NRX RF Power Meter
- DC – 110 GHz (sensor dependent)
- Power Measurement: 0.1 fW – 30 W
- Up to 4 Channels
Bird 4480A RF Wattmeter
- Frequency: 2MHz – 1000MHz
- 10W – 10kW Low Band
- 1W – 1kW High Band
