| Instrument Supply |
115V / 230V ac nominal |
| EUT supply (three phase) |
AC voltage: |
24 - 440V (phase to phase |
| DC voltage: |
1 - 50V |
| Current: |
25A continuous 30A for 30 mins |
| Coupling / decoupling elements |
to IEC 61000-4-5 |
| Coupling modes |
all differential / all common mode / lines to GND |
| Burst coupling option (optional) |
AC voltage: |
24 - 440V (phase to phase) |
| DC voltage: |
1 - 50V |
| Current: |
25A continuous 30A for 30 mins |
| Coupling / decoupling elements |
to IEC 61000-4-4 |
| Coupling modes |
lines to ref. GND all combinations of lines to ref. GND |
Note: The Teseq CDN 131 is a single-phase Coupling Network version.
